Harrington - 1 Drawer Corner TV Unit
Dimensions
Width - 90cm
Depth - 50cm
Height - 60cm
Important
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call t h e A rgos Customer Helpline: 08456 400 800
or Homebase Customer Helpline: 0845 077 8888.
614/4221
129/7908
Issue 1 - 10/09/13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Harrington 614/4221
Summary of Contents for Argos Harrington 614/4221
- Page 1 Harrington - 1 Drawer Corner TV Unit 614/4221 129/7908 Dimensions Width - 90cm Depth - 50cm Height - 60cm Important Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call t h e A rgos Customer Helpline: 08456 400 800 or Homebase Customer Helpline: 0845 077 8888.
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly This product has been produced We do not Check you have all the components and tools listed on from natural timber; you may recommend the notice some variation in the grain use of power pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 3 Right side panel (57,4 x 28,9cm) Top panel Base panel (90 x 50cm) (81,4 x 47,2cm) 6 Left division (48,7 x 44cm) Left side panel (57,4 x 28,9cm) 5 Right division (48,7 x 44cm) Front plinth...
- Page 4 Components - Fittings If you have damaged or missing components, call the Argos Customer Helpline: 08456 400 800 or Homebase Customer Helpline: 0845 077 8888. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Insert dowels into the indicated parts. Insert shelf support pins into side panels and divisions (2x) Step 2 Attach divisions to the fixed shelves using long screws Please note the position s i d of the labels on painel Note! grooves on divisions s i d...
- Page 6 Assembly Instructions Step 3 Fit base panel to the assembled part and fix it using screws Step 4 Fit left side panel the assembled part, then attach it to the base panel using screws Fix foot to the base panel using screws Note: correct position as shown in the diagram before fixing.
- Page 7 Assembly Instructions Step 5 Fix brackets through pre-drilled holes on base panel using screws Step 6 Attention! View from behind! a: Fit top front frame the assembled part. Attention Make sure holes on top front frame are facing up. b: Fit bottom front frame to the assembled part.
- Page 8 Assembly Instructions Step 7 a: Fit right side panel to the front frames and base panel, then fix it to the base panel using screws b: Fix bracket to the bottom front frame using screws as shown. Step 8 Fixing sides and front plinth.
- Page 9 Assembly Instructions Step 9 Fixing top panel Important: With help, carefully stand the product upright. With help, fit top panel to the assembled part then fix it using screws Insert dowels half way through to the holes on base panel, as shown in the diagram.
- Page 10 Assembly Instructions Step 11 Fixing back panels. Important: Product MUST upright and square when back panels are attached. Attach the back panels using nails Step 12 Drawer assembly. Attach drawer sides to the drawer using screws front Slide drawer bottom into slots.
- Page 11 Assembly Instructions Step 13 Insert drawer into unit. Assembly is complete. If you need help or have damaged or missing parts, c a l l t h e Customer Helpline: 08456 400 800...
