4.5.5 RF Leakage from Inactive Outputs

Equipment: Same as in Section 4.5.4
Procedure:
1. Set the unit for full power Standard Coag and
Bipolar Coag. Connect the 200 ohm, nonreactive
resistor in series with the 250 mA RF ammeter.
One at a time, connect that series combination
between the return electrode connector and each
RF output terminal shown in Table 4.3, and
activate the unit using the corresponding com-
mand. Confirm that no meter readings exceed the
specified maximum. Hand control coag activa-
tions are accomplished by connecting a jumper
between the lower black jack and the red jack of
the desired hand switchable accessory jack.
MEASURED OUTPUT
TERMINAL
FOOT ACTIVE
FOOT ACTIVE
FOOT ACTIVE
LEFT HAND ACTIVE
LEFT HAND ACTIVE
LEFT HAND ACTIVE
RIGHT HAND ACTIVE
RIGHT HAND ACTIVE
RIGHT HAND ACTIVE
BIPOLAR TOP
BIPOLAR BOTTOM
Table 4.3 RF Leakage for Inactive Outputs Test
HAND CONTROL ACTIVATIONS
SHOULD BE KEYED USING 3'' OR LESS
WELL INSULATED JUMPER(S). USE OF
AN INSULATING ROD TO INSERT THE
JUMPER IS ADVISED TO PREVENT RF
BURNS.
CAUTION: To avoid destroying the meter, never
activate output terminal connected to the meter.
2. Disconnect the meter and resistor from the
unit. Turn unit Power Switch OFF.
ACTIVATION
COMMAND
LEFT HAND COAG
RIGHT HAND COAG
FOOT BIPOLAR
FOOT COAG
RIGHT HAND COAG
FOOT BIPOLAR
FOOT COAG
LEFT HAND COAG
FOOT BIPOLAR
FOOT BIPOLAR
FOOT BIPOLAR
>WARNING<
MAXIMUM
LEAKAGE (mA)
50
50
20
50
50
20
50
50
20
20
20
