ConMed Sabre 2400 Operators & Service Manual page 14

R
CONNECTIONS:
Monopolar Foot Switch Connector:
Bipolar Foot Switch Connector:
Two Pin Return Electrode Jack:
Bipolar Accessory Jacks:
Hand Switchable Monopolar
Accessory Jack:
Foot Switch Controlled Monopolar
Accessory Jack:
NORMAL USE & ENVIRONMENTAL RESTRICTIONS:
Drip-proof equipment, IPX1
Equipment not suitable for use in the presence of a flammable
anaesthetic mixture with air or with oxygen or nitrous oxide.
Continuous operation with intermittent loading, Duty Cycle 15s on / 30s off.
Operating Ambient temperature range +10
Relative Humidity 30% to 75%
Altitude -60 to +4500 meters (-197 to +14,760 feet) above Sea Level.
Mounting Restriction: 2 inch (5cm) clearance required on each side of unit for cooling.
SHIPPING AND STORAGE ENVIRONMENTAL RESTRICTIONS:
-40 C to +70
O O
packing material and shipping carton.
REGULATORY CERTIFICATION:
UL Listed, Medical and Dental Equipment (E68077)
ISO 9002: 1994 Registered Facility
POWER CORD: AWG 16-3 Yellow, Type ST, 15' 6" (4.7 M) [-002 model only]
WEIGHT: 32 lb. (14.5 Kg)
HEIGHT: 6.75 inches (17.1 cm)
WIDTH: 14.25 inches (36.2 cm)
DEPTH: 21.5 inches (54.6 cm)
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
REM TM is a trademark of Valleylab, Inc.
1-8
C; 10% to 95% Relative Humidity when sealed in original polybag,
Threaded, 4 Pin
Threaded, 3 Pin
A.R.M. and REM TM compatible connector
Two blue banana jacks for RF output, plus black
miniature banana jack referenced to bottom blue jack for
handswitched bipolar operation.
Two sets of 3 banana jacks (two black and one red)
Bovie #12 Standard Active
C to +40 C
O O
