V 4.0
Axial Pump Water Seal Kit
INTRODUCTION
This water seal kit replaces the water seal and o-ring components on the 3 GPM @
2,700 PSI Axial Pressure Washer Pump Assembly (SKU 8605412). Consult the
User's Manual for the Pressure Washer Pump Assembly before installation and
follow all safety instructions in that manual.
SAFETY
WARNING! Read and understand all instructions before using this tool. The
operator must follow basic precautions to reduce the risk of personal injury
and/or damage to the equipment.
1.
Operate in a safe work environment. Keep your work area clean, well lit and
free of distractions.
2.
Always wear impact safety goggles that provide front and side protection for
the eyes. Eye protection equipment should comply with CSA Z94.3-07 or ANSI
Z87.1 standards based on the type of work performed.
3.
Wear protective clothing designed for the work environment and tool.
ASSEMBLY & INSTALLATION
References to the Parts List in manual 8605412 are represented by the pound
symbol (#). Tools and components required for replacement:
• Part# 15 (Oil Seal) x 3
• Part# 18 (O-ring)
• Torque Wrench
• Axial Pump Water Seal Installation Tool (SKU 8630121, sold separately)
• Circlip Pliers
Please read and understand all instructions before use. Retain this manual for
future reference.
• Part# 16 (O-ring)
• Part# 19 (Compaction Flake)
• Wrench, 9/16 in. (14 mm)
8624736
• Part# 17 (Spacer)
• Part# 20 (Water Seal)
• Allen Wrench
Advertisement
Table of Contents
Related Manuals for Power Fist 8624736
Summary of Contents for Power Fist 8624736
- Page 1 V 4.0 8624736 Axial Pump Water Seal Kit INTRODUCTION This water seal kit replaces the water seal and o-ring components on the 3 GPM @ 2,700 PSI Axial Pressure Washer Pump Assembly (SKU 8605412). Consult the User’s Manual for the Pressure Washer Pump Assembly before installation and follow all safety instructions in that manual.
- Page 2 8624736 Axial Pump Water Seal Kit V 4.0 WATER SEAL MAINTENANCE Check that the water seal kit has all the components before disassembling the pump. Hold the pump firmly. Use an Allen wrench to loosen the four bolts (#55). Remove water inlet body (#42) and set aside. Remove the manifold and lay the head assembly on a flat surface (Fig.
- Page 3 V 4.0 Axial Pump Water Seal Kit 8624736 WATER CHECK O-RING KIT Check that the Water Check O-ring Kit has all the components before disassembling the pump. Hold the pump firmly. Use an Allen wrench to loosen the four bolts (#55).
- Page 4 8624736 Axial Pump Water Seal Kit V 4.0 For technical questions call 1-800-665-8685...
- Page 5 V4,0 8624736 Trousse de joint hydraulique de pompe axiale INTRODUCTION Cette trousse de joint hydraulique remplace les composants de joint hydraulique et joint torique sur l'ensemble de pompe axiale de laveuse à pression de 3 gal/min à 2 700 lb/po carré (UGS 8605412). Consultez le manuel de l'utilisateur de l'ensemble de pompe de laveuse à...
- Page 6 8624736 Trousse de joint hydraulique de pompe axiale V4,0 • Clé Allen • Anneau élastique • Outil d'installation de joint hydraulique de pompe axiale (UGS 8630121, vendu séparément) ENTRETIEN DU JOINT HYDRAULIQUE 1. Avant de démonter la pompe, assurez-vous que la trousse de joints hydrauliques comporte tous les composants.
- Page 7 V4,0 Trousse de joint hydraulique de pompe axiale 8624736 TROUSSE DE JOINT TORIQUE DE BAGUE D'ARRÊT Avant de démonter la pompe, assurez-vous que la trousse de joints toriques comporte tous les composants. Tenez la pompe solidement. Desserrez les quatre boulons (n 55) au moyen d'une clé...
- Page 8 8624736 Trousse de joint hydraulique de pompe axiale V4,0 En cas de questions techniques, appelez le 1-800-665-8685...
