CADD Legacy Plus 6500 Operator's Manual page 94

Section 5: Reference
Volumetric Accuracy Testing
Description
A predetermined amount of water is delivered into a collection device
such as a burette or graduated cylinder. The amount of water delivered is
compared to the amount that the pump is programmed to deliver.
Nominal system accuracy is given in the technical specifications section
for the pump. That is, under the test conditions described below, the ac-
curacy of the pump and Medication Cassette Reservoir will be nominal
with a 90% confidence level. The nominal test conditions are as follows:
degassed water at 25 ± 5°C without back pressure.
Equipment needed
50 or 100 ml Medication Cassette Reservoir with attached CADD™
Extension Set with Anti-Siphon Valve OR
50 or 100 ml Medication Cassette Reservoir with flow stop feature
with attached CADD™ Extension Set (catalog numbers start with
21-73xx)
50 or 60 ml syringe
A fluid collection device such as a burette or a Class A, 25 ml capac-
ity graduated cylinder
40 ml of room temperature water
Procedure
1. Fill the 50 or 60 ml syringe with 40 ml of water. Transfer the water
into a Medication Cassette Reservoir.
2. Remove any air from the Medication Cassette Reservoir by aspi-
rating the air with the syringe. Attach the CADD™ Extension Set.
Prime the tubing so it is filled with fluid to the end of the extension
set Luer.
3. Attach the end of the extension set to the fluid collection device.
4. Attach the cassette to the pump. Program the Reservoir Volume to
20 ml. This is the intended delivery volume. Remove all clamps.
