Inserting the Tubing into the Air Detector

WARNING: When the Air Detector is turned off, the pump will not
detect air in the fluid path. Periodically inspect the fluid path and
remove any air to prevent air embolism. Air embolism could result in
death or serious injury to the patient.
(See Section 4, Biomed Functions, for instructions on how to turn the air
detector on and off.)
1. If the Air Detector is in use, make a small loop of tubing under-
neath the air detector and hold it with your thumb.
2. Place the tubing over the groove in the air detector and tuck it
under the catch.
Catch
Section 2: Pump Setup and Programming
