CMS200
1.5 Environmental ratings
Characteristic
IP Rating
Maximum operating temperature
Minimum operating temperature
Housing material
Operating control
Construction
Software Class
Limitation of operating control
Action
Control pollution degree
Rated impulse voltage
Temperature ball pressure test
*All SELV circuits (signal and data connectors) separated from mains by reinforced insulation
Before beginning installation, remove all protective film from between the seals of the CDM (control display
module). The seals are malleable, to ensure a water resistant seal around cables and prevent water ingress.
www.nexo.com
Power supply module
IPX5
Sub Zero PSM: 55°C (131ºF)
0ºC (32ºF)
Black polycarbonate, Food grade
(non-contact)
Electronic Thermostat
Incorporated Class II control
for use in Class I or Class II
appliances
Class A
Continuous
Type 1B
Degree 2
Loads 2.5KV
Control 330V (SELV*)
160ºC (PCB)
125ºC (Enclosure)
Page 13
Product Manual, Issue 6
Control display module
IP65 Front Facia, IP24 All Over
55ºC (131ºF)
-10ºC (14ºF)
Black polycarbonate, Food grade
(non-contact)
Electronic Thermostat
Class II (SELV electronic control)
Class A
Continuous
Type 1B
Degree 2
Loads 2.5KV
Control 330V (SELV*)
160ºC (PCB)
125ºC (Enclosure)
75ºC (front face)
