Relay Ratings; Temperature Input Ranges - Elstat Nexo CMS200 Product Manual

Product Manual, Issue 6
1.3 Relay ratings
Relay
Compressor
Lights
Evaporator fan
Auxiliary
Note
The auxiliary relay is normally used to switch a defrost heater, or a solenoid valve, for hot
gas defrosts.
Note
This controller is designed for integration into 3rd party equipment only and should
be installed according to these instructions and all relevant local electrical and safety
standards.
1.4 Temperature input ranges
Sensor
Appliance sensor
Condenser sensor
Evaporator sensor
Note
The NTC thermistor from Elstat is rated at -35ºC to 125ºC (-31ºF to 257ºF).
Maximum IEC rating @ 100 – 240VAC
10(10)A, p.f. 0.6
4(4)A, p.f. 0.6
6(6)A, p.f. 0.6
6(6)A, p.f. 0.6
Input range (ºC)
-15ºC to 50.0ºC +/- 0.5ºC
50ºC to 125ºC +/- 5.0ºC
-15ºC to 50ºC +/- 0.5ºC
Page 12
Maximum UL ratings @ 120V
10FLA, 60LRA
250W Ballast
6FLA, 36LRA
6FLA, 36LRA
Input range (ºF)
5ºF to 122ºF +/- 1ºF
122ºF to 257ºF +/- 10ºF
5ºF to 122ºF +/- 1ºF
CMS200
www.nexo.com
