Product Manual, Issue 6
The control display module is available with either an integrated or a remote motion sensor. Both CDM
variants are made from food grade plastics and are safe for internal installation.
Controller with integrated motion detection
1
2
This variant should always be installed where the
sensor can 'see' activity. It is recommended that the
CDM is installed externally on the cooler.
Item
LED
1
Compressor
2
Evaporator fan
Saving
3
temperature
disable
4
Motion
Push
Item
Button
5
Set
6
Down
7
Up
8
Defrost
9
Logo
10
LED Display
11
Sensor
(IMD)
9
11
10
3
4
Indicator
On when the compressor is running.
On when evaporator fan is running.
On if the saving mode temperature is disabled.
The controller maintains the Ready mode temperature at all times.
On when motion is detected.
Name
Accept/forward - selects menu options and parameters.
Scrolls down menus. Decreases parameter values. Cancels the rSF,
d0 and Ht alarms.
Scrolls up menus. Increases parameter values.
Return/backward - De-selects menu options and parameters.
Activates a manual defrost (only applicable if controller is set to
timed defrost and temp is below termination temp).
Elstat logo
3-digit 7-segment LED display
Motion sensor
Controller with remote motion detection
5
6
This variant of the CDM can be installed internally
on the cooler but the remote motion sensor must
be installed where it can 'see' activity.
Function
Function
Page 6
CMS200
(RMD)
7
8
www.nexo.com
