USER 1 - 24V
2300A24
24V
ELECTRONIC CONTROL UNIT FOR SLIDING GATES AND BARRIERS
SEA USA Inc.
10850 N.W. 21st unit 160 DORAL MIAMI
Florida (FL) 33172 USA
Tel.
:++1-305.594.1151 ++1-305.594.7325
-
Toll free:
800.689.4716
web site: www.sea-usa.com
e-mail: sales@sea-usa.com
67411071
REV 01 - 05/2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USER 1-24V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SEA USER 1-24V

  • Page 1 International registered trademark n. 2.777.971 USER 1 - 24V 2300A24 ELECTRONIC CONTROL UNIT FOR SLIDING GATES AND BARRIERS SEA USA Inc. 10850 N.W. 21st unit 160 DORAL MIAMI Florida (FL) 33172 USA Tel. :++1-305.594.1151 ++1-305.594.7325 Toll free: 800.689.4716 web site: www.sea-usa.com e-mail: sales@sea-usa.com...
  • Page 2 • Only qualified personnel can install, repair and periodically check this equipment. • The User must not attempt to repair or to take direct action on the system and must solely contact qualified SEA personnel or SEA service centres. User can apply only the emergency manual function.
  • Page 3 USER 1 - 24V International registered trademark n. 2.777.971 INSTALLATION WARNINGS • For gate operators: install only when A. The operator is appropriate for the gate’s construction and usage Class. B. All opening spaces on the wall of the horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet (1m) above the ground so that it could be possible to keep on the entire surface of the wall a minimum distance of 2-1/4 (57,15mm) inches from the gate and the wall on which the gate runs.
  • Page 4 USER 1 - 24V International registered trademark n. 2.777.971 CONNECTIONS Only with battery charger card (Cod.23101105) Accessories Max 200 mA 67411071 REV 01 - 05/2011...
  • Page 5 USER 1 - 24V International registered trademark n. 2.777.971 CONNECTIONS LIMIT SWITCH PROGR RX ENCODER Connector programmer OPEN RADIO MODULE Receiver module connector DIP SWITCH JOLLY POWER feed connector Connector Programmer Jolly 67411071 REV 01 - 05/2011...
  • Page 6: Table Of Contents

    USER 1 - 24V International registered trademark n. 2.777.971 INDEX COMPONENTS’ DESCRIPTION ....................7 GENERAL INFORMATION ......................8 START, STOP, PEDESTRIAN START, ANTENNA, PHOTOCELL CONNECTIONS.....9 ENCODER, LIMIT SWITCH, WARNING LAMP, EDGE..............10 POWER SUPPLY AND MOTORS CONNECTIONS ..............11 SELFLEARNING DEFAULT SETTING..................11 WORKING TIMES SELFLEARNING ..................12 SETTINGS’...
  • Page 7: Components' Description

    USER 1 - 24V International registered trademark n. 2.777.971 DESCRIPTION OF THE COMPONENTS CALM - S + 24Vaux Motor Light LED 21 LED 23 FUSE 24Vaux LIGHT LED 22 FLASH FLASH SET MOT PWR SET MOT PWR ENCODER LED 1 GATE TYPE LED 2 PAUSE...
  • Page 8: General Information

    USER 1 - 24V International registered trademark n. 2.777.971 GENERAL INFORMATION The information in this section of the manual are only for technicians or for qualified or authorized installers. GENERAL CHARACTERISTICS The USER 1 24V control unit has been designed to manage one low voltage motor with or without electronic limit switches. It is of very small dimensions and besides the possibility to adjust motor speed, amperemetric anti squeezing sensitivity, leaf delay in closing, pausing time, it is also possible to manage a display, through which it is possible to control a lot of management functions and the maintenance of the control unit.
  • Page 9: Start, Stop, Pedestrian Start, Antenna, Photocell Connections

    USER 1 - 24V International registered trademark n. 2.777.971 START - STOP - PEDESTRIAN START - ANTENNA - PHOTOCELL Photocell 1 Connection When the ray of the photocell is crossed, and the automation is in phase of closing it reverses its movement.
  • Page 10: Encoder, Limit Switch, Warning Lamp, Edge

    USER 1 - 24V International registered trademark n. 2.777.971 ENCODER - LIMIT SWITCH Encoder / Ammeter sensor The encoder is a device that allows to reveal possible obstacles during the opening and the closing of the gate. When this device intervenes in opening it causes the inversion of the movement for around a second, if it intervenes in closing it causes the total reopening.
  • Page 11: Power Supply And Motors Connections

    USER 1 - 24V International registered trademark n. 2.777.971 MOTOR POWER SUPPLY 3,6 A delayed fuse on 230V ~ power supply . Motor 6,3A delayed fuse on 115V ~ power supply. connection 115V~ 230V~ M+M- CONFIGURATION FOR VERG For the application on the VERG it is recommended to use the speed levels indicated on the following Power input board:...
  • Page 12: Working Times Selflearning

    USER 1 - 24V International registered trademark n. 2.777.971 WORKING TIMES SELF LEARNING Note1: it is not necessary to put a jumper between the STOP, PHOTOCELL contacts if they are not used. If Fig. 1 they are used during selflearning phase they must stay (N.C.). Note2: If accessories are connected on the BUS, align the photocells before programming, as shown in the description of the BUS system.
  • Page 13: Settings' Selection

    USER 1 - 24V International registered trademark n. 2.777.971 SELECTION OF THE SETTINGS The adjustments of the control unit are executed through the buttons "MENU" and "SET” . Pressing the "MENU” button you select the Leds corresponding to the various functions to be set, pressing the “SET” button you select the leds corresponding to the desired values inside every single function.
  • Page 14: External Receiver Connection And Radio Transmitter Learning

    USER 1 - 24V International registered trademark n. 2.777.971 EXTERNAL RECEIVER Example: Connection of a radio receiver For the connection of the receiver refer to the relative instructions manual. RADIO TRANSMITTER SELF LEARNING WITH RECEIVER ON BOARD OF CONTROL UNIT WARNING: Make the radio transmitters programming before you connect the antenna and insert the receiver into the special CMR connector (if available) with turned off control unit.
  • Page 15: Functioning Logics

    USER 1 - 24V International registered trademark n. 2.777.971 FUNCTION LOGIC AUTOMATIC LOGIC A start impulse opens the gate. A second impluse during the opening will not be accepted. A start impulse during closing reverses the movement. Jolly option: To activate the automatic re-closing put DIP1 and DIP4 on ON. With DIP2 and DIP4 on ON start in pause is activated If you dispose of a Jolly programmer it is possible to SECURITY LOGIC...
  • Page 16: Master Slave Function

    USER 1 - 24V International registered trademark n. 2.777.971 MASTER-SLAVE FUNCTION SLAVE MASTER CALM - S + 24Vaux Motor Light FUSE LIGHT 24Vaux LED 21 LED 23 LED 22 FLASH FLASH SET MOT PWR SET MOT PWR ENCODER GATE TYPE LED 1 PAUSE SET LEDS...
  • Page 17: Programmer Jolly Parameters Adjustment

    USER 1 - 24V International registered trademark n. 2.777.971 PROGRAMMER JOLLY PARAMETERS ADJUSTMENT The JOLLY programmer allows to keep under control and to change all parameters of the control unit without need to use the SET and MENU buttons of the control unit. Furthermore, it is essential for the initial setting of some parameters which are not settable directly on the control unit which are: selftest photocell, photocell in opening, anti-intrusion, separate regulation of the motor torque in opening and closing, slow-down speed, learning speed, acceleration, deceleration, leaf stroke, number of cycles, pedestrian opening, foto/timer, ped/Timer, 24Vaux, control lamp, balanced edge, closing with photocell.
  • Page 18 USER 1 - 24V International registered trademark n. 2.777.971 PROGRAMMER JOLLY PARAMETERS ADJUSTMENT NOTE: For the respect of the valid European ruels on the safety of the electric gates, it is recommended to not adjust the parameters torque Max 1 and torque Max 2 on the value 100%. It allows to regulate the duration of the acceleration of the motors on the start If on 100% the gate will...
  • Page 19: Connection Of Batteries

    USER 1 - 24V International registered trademark n. 2.777.971 CONNECTION OF BATTERIES TO BATTERY CHARGER CARD (BAT) Battery signals: Cod.23101110 - Batteries loaded up to 20V: green led turned on, red led turned off. = charge 200mA -Batteries with tension between 20 and = charge 360mA 18V: green led flashes, red led is off ;...
  • Page 20: Trouble Shooting

    USER 1 - 24V International registered trademark n. 2.777.971 TROUBLE SHOOTING Advises Make sure all Safety LED are turned ON All not-used N.C. contacts must have jumpers Problem Found Possibile Cause Solution Motor doesn’t a.) Check the connections or the a.) Jumper missing on one of the jumpers on the connections of the N.C.
  • Page 21: Sales Conditions

    SEA. Recognized defects, whatever their nature, will not produce any responsibility and/or damage claims to SEA USA Inc and SEA s.r.l. Warranty shall not cover any required labor activities. Warranty will in no case be recognized if alterations and any other changes will be found on products. Warranty will not cover damages caused by carriers, expendable materials and faults due to improper use with the products specifications.
