Example of Internal Circuit and Wiring
50 50
- -22(L)-(M)
ZSE F/ISE
60 60
With analog output
1kΩ
50 50
- -62(L)-(M)
ZSE F/ISE
60 60
With analog output
1kΩ
For General Fluids
High Precision Digital Pressure Switch
DC (+)
(Brown)
Analog output
(Gray)
OUT 1
(Black)
OUT 2
(White)
DC ( )
(Blue)
DC (+)
(Brown)
Analog output
(Gray)
OUT 1
(Black)
OUT 2
(White)
DC ( )
(Blue)
50 50
ZSE F/ISE
60 60
With auto shift input
6.8KΩ
12VDC
to
24VDC
50 50
ZSE F/ISE
60 60
With auto shift input
1.2KΩ
6.8KΩ
12VDC
to
24VDC
ZSE50F/ISE50
Series
- -30(L)-(M)
DC (+)
(Brown)
1.2KΩ
Auto shift input
(Gray)
OUT 1
(Black)
OUT 2
(White)
DC ( )
(Blue)
- -70(L)-(M)
DC (+)
(Brown)
Auto shift input
(Gray)
OUT 1
(Black)
OUT 2
(White)
DC ( )
(Blue)
12VDC
to
24VDC
12VDC
to
24VDC
