SMC Networks ZSE50F Manual page 2

Pressure detection for a wide range of fluids.
Hydraulic fluid ( JIS-K2213 )
Silicon oil
Lubricating oil ( JIS-K6301 )
Fluoro carbon
To confirm absorption of work piece with
water on the surface, e.g. wet LCD glass
plate
To measure hydraulic pressure
Using of stainless steel diaphragm
The stainless steel diaphragm prevents direct
contact between sensor and measured fluid.
Liquid and gas contact areas
Fittings
Extremely low leakage
Sensor and fittings are electron-beam welded.
Leakage is kept at the lowest level by using VCR
and Swedgelok
ZSE50F / ISE50
ZSE60F / ISE60
IP65
Enclosure
Panel mount
Option
Panel mount + Front side protection cover
To confirm adsorption of work
Application
pieces containing water
examples
Features 1
( JIS-K2213 )
SUS630
SUS304
fittings.
€
-5
1 x 10 Pa⋅m 3 /s
-10
1 x 10 Pa⋅m 3 /s
€
With bracket
To confirm primary pressure
of cleaning line
Argon
Air containing drain
Ammonia
Freon
Carbon dioxide
Nitrogen
To measure low-quality air,
containing drain
Leakage test with nitrogen
Pressure sensor
Fitting
Stainless steel diaphragm
To confirm working pressure of
hydraulic cylinder
