For positive pressure
For compound pressure
A2
B2
∗URJ 1/4 and TSJ 1/4 are special fittings for semiconductor
manufacturing equipment.
Analog output
ZSE60F/ISE60- -22/62(L)-(M)
Suitable mode:
Series ISE60
5
1
0
1.0MPa
Pressure
Option
When option parts are required separately, use the following part numbers to
place an order.
Option
Bracket A
Bracket D
Panel mount
Panel mount + Front protection cover
9
For General Fluids
High Precision Digital Pressure Switch
ZSE60F/ISE60
Series
How to Order
ISE60
ZSE60 F
Piping specifications
∗
URJ 1/4 , Piping in the backward direction
∗
TSJ 1/4 , Piping in the backward direction
Input/output specifications
22
NPN open collector 2 output + Analog output
30
NPN open collector 2 output + Auto shift input
62∗
PNP open collector 2 output + Analog output
70∗
PNP open collector 2 output + Auto shift input
∗
Optional
Note) Auto shift input is used for the auto shift function.
For more information, please refer to Auto Shift Function on
page 5.
Series ZSE60F
5
1
100kPa
100kPa
Pressure
Part no. Qty. Note
ZS 24 A 1 With 2 pcs. of mounting screws
ZS 24 D 1 With 2 pcs. of mounting screws
ZS 24 E 1
ZS 24 F 1
A2 22
L
A2 22 L
Lead wire length
L
3m
M
M
Option
Nil None
Bracket A
A
Bracket D
Refer to the dimensions for
D
the difference between bra-
ckets A and D.
Panel mount
E
Panel mount + Front protection cover
F
Unit specification
Nil With unit switching function
M Note 2)
Fixed SI unit
Note1) Under the New Measurement Law, which
has been in effect since October, 1999,
sales of switches with the unit conversion
function have not been allowed for use in
Japan.
Note 2) Fixed units:
For compound pressure : KPa
For positive pressure : MPa
Note 1)
