A S S E M B LY I N S T R U C T I O N S
The Cambridge Raised Planter Box
Please read through before starting assembly.

Check Box for These Contents

In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
1. Pre-Assembled Side Wall Panels with Posts Connected (2)
2. Floor Panels (4)
3. Floor Support (1)
4. Front and Back Wall Panels (2)
5. Pre-assembled Shelf (1)
6. Post Caps (4)
7. 5/8" Stainless Steel Screws (12)
8. 1 1/2" Stainless Steel Screws (8)

General Information

• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 4'x 8' for unobstructed assembling.
• You should not need to use excessive force when assembling components.
1
6
www.newenglandarbors.com
2
5
3
7
8
Not to Scale
4
1
Ver 3.2/101515

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The Cambridge Raised Planter Box and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for New England Arbors The Cambridge Raised Planter Box

  • Page 1 A S S E M B LY I N S T R U C T I O N S The Cambridge Raised Planter Box www.newenglandarbors.com Please read through before starting assembly. Check Box for These Contents In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
  • Page 2 The Cambridge Raised Planter Box S T E P O N E Lay the Pre-Assembled Side Wall Panel on the floor as shown and align and insert the pre-assembled shelf into the routed hole. Do the same for the Front and Back Wall Panels as shown.
  • Page 3 The Cambridge Raised Planter Box S T E P O N E ( C O N T ’ D ) Fasten the wall panels together using 4 of the 5/8” screws provided through the pre-drilled holes on the posts as shown.
  • Page 4 The Cambridge Raised Planter Box Notch S T E P T W O ( C O N T ’ D ) Place the four floor panels onto the floor supports as shown. Note the notches on the one side of the end panels. The notches are to wrap around the posts.
