Doc. No. MGQ*-OM0001C-A
PRODUCT NAME
Compact Guide Cylinder
MODEL/ Series
MGQ
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MGQ Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMC Networks MGQ Series

  • Page 1 Doc. No. MGQ*-OM0001C-A PRODUCT NAME Compact Guide Cylinder MODEL/ Series Series...
  • Page 2: Table Of Contents

    Contents Safety Instructions Product feature 1. How to Order 2. Model 3. Specifications 4. Standard strokes 5. Intermediate stroke 6. Weights 7. Weights of moving parts 8. Allowable Kinetic Energy 9. Precautions on Selection 10. Precautions on Design 11. Mounting Methods 12.
  • Page 3: Safety Instructions

    Series MGQ Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC), Japan Industrial Standards (JIS)*1) and other safety regulations*2).
  • Page 4 Series MGQ Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
  • Page 5: Product Feature

    Product features...
  • Page 6: How To Order

    1. How to Order 2. Model Model Cushion Bearing type Bore size(mm) Slide bearing MGQ□□-□ Rubber bumper 12,16,20,25,32,40,50,63,80,100 Ball bushing 3. Specifications Model MGQ□□-□ Double acting Action Fluid 1.5MPa Proof pressure 1.0MPa Maximum operating pressure φ12, φ16 0.12MPa Minimum operating pressure φ...
  • Page 7: Standard Strokes

    4. Standard strokes Model Bore size(mm) Standard stroke(mm) 12,16 10,20,30,40,50,75,100 □-□ 20,25 20,30,40,50,75,100,125,150,175,200 32 to 100 25,50,75,100,125,150,175,200 5. Intermediate strokes Spacer installation type Exclusive body (-XB10) Spacers are installed in the standard stroke Dealing with the stroke by making an exclusive cylinder.
  • Page 8: Weights Of Moving Parts

    7. Weights of Moving Parts Slide Bearing:MGQM12 to 100 (kg) Standard stroke (mm) Bore size Model (mm) MGQM12 0.12 0.13 0.14 0.15 0.16 0.19 0.21 MGQM16 0.17 0.19 0.20 0.22 0.23 0.26 0.30 MGQM20 0.28 0.30 0.33 0.62 0.44 0.50 0.56 0.62 0.68...
  • Page 9: Precautions On Selection

    9. Precautions on Selection 1) Confirm the specifications. Products represented in this manual are designed only for use in compressed air systems. Do not operate at pressures or temperatures, etc., beyond the range of specifications, as this can cause damage or malfunction. (Refer to the specifications.) Please contact SMC when using a fluid other than compressed air made by pneumatic equipment.
  • Page 10: Mounting Methods

    6) Consider a possible loss of power source. Measures should be taken to protect against human injury and equipment damage in the event that there is a loss of power to equipment controlled by air pressure, electricity or hydraulics,etc. 7) Design circuitry to prevent sudden lurching of driven objects. When a cylinder is driven by an exhaust center type directional control valve or when starting up after residual pressure is exhausted from the circuit, etc., the piston and its driven object will lurch at high speed if pressure is applied to one side of the...
  • Page 11 4) Do not perform additional machining to the product. Additional machining to the product can result in insufficient strength and cause damage to the product. This can lead to possible human injury and damage to the surrounding equipment. 5) Do not enlarge the fixed throttle by modifying the pipe connectors. If the hole diameter is enlarged, the product’s rotation speed will increase, causing the shock force to increase and damage to the product.
  • Page 12: Piping

    12. Piping 12-1. Attention in piping 1) Use clean air. If compressed air includes chemicals, synthetic oils containing organic solvents, salt or corrosive gases, etc., it can cause damage or malfunction. 1)Secure dry air. If moisture enters cylinder, grease inside the cylinder is washed away and air leak and malfunction may occur due to deterioration of lubrication.
  • Page 13: Operating Environment

    13. Operating Environment 1) Do not use in environments where there is a danger of corrosion. Refer to the construction drawings regarding cylinder materials. 2) In dirty areas, such as dusty locations or where water, oil, etc. splash on the equipment, take suitable measures to protect the entire actuator.
  • Page 14: Troubleshooting

    15. Troubleshooting Nonconformit Causes Countermeasures Remarks Lower operating speed Consider providing low speed than the limit specification. No smooth operation Increase Pressure. High load factor Use larger cylinder. Meter-in speed controller Change it to meter-out. Use heat resistant cylinder. High ambient temperature (Type M only) Use cold resistant cylinder.
  • Page 15: How To Exchange Seals

    16. How to exchange seals Disassemble and assemble the cylinder in clean condition. Wipe it with clean waste. 16-1.How to disassemble Tools : Snap ring plier for hole, Spanner, Socket wrench (or Air impact wrench) 1) Fix the spanner flat of piston rod with a spanner. Loosen the plate set bolt with the socket wrench to remove the guide rod assembly.
  • Page 16 3) Gasket Use precision screw driver etc. 16-3. How to apply grease Use the grease pack:GR-S or lithium soap radical grease JIS2 corresponding. 1) Rod seal Apply grease slightly to outer circumference of new seal for replace. This helps the seal to accustom to the collar. For the grove, fill it with grease. This is necessary for operation.
  • Page 17: Construction

    17. Construction...
  • Page 19: Auto Switch

    18. Auto Switch 18-1. Applicable auto switches 18-2. Auto switch proper mounting position (detection at stroke end) and Its mounting height...
  • Page 20 18-3. Minimum mountable stroke for a cylinder with auto switch(es) 18-4. Auto switch operating range 18-5. Part number of auto switch mounting bracket...
  • Page 21 Revision history Initial release : 1998/8/25 All revised Revision 1 : 2014/1/30 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
