Forest-Master Fast Fire FM6FFE Manual page 11

Remove the bolts and nuts from the bottom of the rear legs. Attach the Stand Rear Axle (part 5) to the
bottom of the rear legs using the bolts and nuts.
Attach the rear wheels (part 3) to the axles using the split pins provided. These go through the holes in
the end of the axles.
Remove the bolt and nut from the Stand Long Brace (part 4) and the bolt from the nut on the locating
tube in the centre of the rear axle.
Insert the Long Brace through the guide tube in the rear axle and into the socket on the rear of the front
castor assembly, so that the holes in the front of the Long Brace line up with the holes in the socket
on the castor assembly. Insert the bolt throught the castor assembly socket and secure with the nut.
Secure the Long Brace to the rear axle guide tube using the bolt. Note there is no hole in the Long Brace
for this bolt, it simply tightens up against the Long Brace.
FM6FF & FM8FF (Electric & Petrol) 11
