ELSA Lancom DSL/10 Office Manual page 95

The menu has the following layout:
/Routing-method
Routing-method
ICMP-routing-method
This option allows you to define the routing method used for IP packets:
Routing-method
If you select 'Normal', all IP packets are handled in the same way as per the routing
K
specifications of the Internet protocol.
If you select 'Type-of-service', IP packets are placed in the urgent queue or reliable
K
queue, depending on the contents of the 'Type-of-service' field. All other packets
are placed in the normal send queue. In this way, transmission is guaranteed,
provided that it is possible.
ICMP-routing- This option allows you to define the routing method used for ICMP packets:
method
If you select 'Normal', the ICMP packets are handled like any other IP packets as per
K
the routing specifications of the Internet protocol.
If you select 'Reliable', all ICMP packets received are placed in the reliable queue.
K
Setup/IP-router-module/RIP-configuration
This option allows you to enter settings for the management of IP-RIP packets. The menu
has the following layout:
/RIP-configuration
Type
R1-mask
Table-RIP
Type This option allows you to select the method to be used for handling the IP-RIP packets.
The different settings have the following meaning:
Off: IP-RIP is not supported (default).
K
RIP-1: RIP-1 and RIP-2 packets are received but only RIP-1 packets are sent.
K
R1-comp: RIP-1 and RIP-2 packets are received. RIP-2 packets are sent as an IP
K
broadcast.
RIP-2: Same as R1-comp except that all RIP packets are sent to the IP multicast
K
address 224.0.0.9.
Description of the menu options
Routing method settings
Routing method for IP packets
Routing method for ICMP packets
Settings for IP-RIP operation
RIP compatibility switch
Management of network masks
Dynamic IP routing table
ELSA LANCOM DSL/10 Office
R39
