ELSA Lancom DSL/10 Office Manual page 104

R48 Description of the menu options
/Firmware
Timeout-firmesafe
Test-firmware
Firmware-upload
The version table displays the firmware version and serial number of the device.
Version table
Ifc
Ifc
This table provides the following details for the two firmware versions stored in the
Table firmsafe
device: the position in memory (1 or 2), status information (active or inactive), the version
number, the date, the size and the index (sequential number).
Position
1
2
3
Enter the following command to activate an inactive firmware version:
set <position number> active
on.
Mode-firmsafe Only one of the firmware versions stored in the device can be active at any one time.
When new firmware is loaded the inactive firmware is overwritten. You can decide
which firmware will be activated after the upload:
'immediate': The first option is to load the new firmware and activate it
K
immediately. The following situations can result:
– The new firmware is successfully loaded and then operates as desired.
– However, if the new firmware does not operate correctly, it may not be possible
'login': To prevent problems caused by defective firmware, the second option will
K
load the firmware and start it immediately.
– In contrast to the first option, the firmsafe will wait until it has successfully
ELSA LANCOM DSL/10 Office
Module
LANCOM DSL/10 Office
Status Version
Inactive 1.70
Active 1.70
<Lader> 1.60
Everything is then in order.
to communicate with the device after the restart. If an error occurs during the
upload, the device automatically reactivates the previous firmware version and
reboots the device.
logged on over outband or inband (by telnet). In contrast to the first option, the
firmsafe will wait until it has successfully logged on (by telnet). The new
Display and keyboard settings
Time in minutes required to test new firmware
Tests the inactive firmware
Initiates a firmware upload
Version
1.70.0006 / 01.09.1999
Date Size
30081999 535
01091999 366
01091999 64
Serial number
8427.000.020
Index
6
7
0
