R18 Description of the menu options
This list is sorted according to the frequency of requests. When the table is full, the
names that have not been requested for the longest period will be deleted to make room
for new entries.

Status/IP-router-statistics

This menu groups together the statistics from the IP router module.
/IP-router-statistics
IPr-LAN-rx
IPr-LAN-tx
IPr-LAN-local-routings
IPr-LAN-network-errors
IPr-LAN-routing-errors
IPr-LAN-ttl-errors
IPr-LAN-filters
IPr-LAN-discards
IPr-WAN-rx
IPr-WAN-tx
IPr-WAN-network-errors
IPr-WAN-ttl-errors
IPr-WAN-filters
IPr-WAN-discards
IPr-WAN-type-errors
IPr-ARP-errors
Delete-values
Establish-table
Protocol-table
RIP-statistics
Establish-table The establish table contains the last 100 entries, which provide information on the
system time, destination and source addresses, IP protocol, destination port and source
port of the data packets that should have caused a connection to be established.
ELSA LANCOM DSL/10 Office
Statistics from the IP router area
Number of data packets to be routed from the LAN
Number of data packets routed to the LAN
Number of packets received from the LAN and routed to the
LAN
Number of LAN packets that were not routed
Number of LAN packets that must be sent to another router
Number of LAN packets with an expired time-to-live value
Number of LAN packets filtered by the filter table
Number of LAN packets discarded
Number of data packets to be routed from the WAN
Number of data packets routed to the WAN
Number of WAN packets that were not routed
Number of WAN packets with an expired time-to-live value
Number of WAN packets filtered by the filter table
Number of WAN packets discarded
Number of packets from the WAN without an IP router ID
Number of unsuccessful accesses to the ARP cache
Deletes IP router statistics
Table of the last 100 packets that required a connection
Table of routed packets arranged by protocol
Statistics from the IP/RIP area
