Status

The Status menu contains information on the current status and the internal sequences
of operations in the LAN and WAN, which can relate to the data transmission route (e.g.
dialing or connection) or to statistics (e.g. number of calls received or data blocks
transmitted). The statistics displays are an important aid for verifying correct functioning
and optimizing parameter settings. In addition, they provide valuable information for
error analysis when malfunctions occur.
Most status displays are continually updated and can be deleted with a value or set to
0 in the current menu.
The menu has the following layout:
Status
Connection
Current-time
Operating-time
WAN-statistics
LAN-statistics
PPP-statistics
TCP-IP-statistics
IP-router-statistics
Config-statistics
DNS-statistics
Queue-statistics
Connections-statistics
Info-connection
Remote-statistics
Channel-statistics
Time-statistics
Delete-values
Description of the menu options
Running status displays
Status of the WAN route
Current time in device
Period of time the device has operated since it was last switched
on
Displays WAN statistics
Displays LAN statistics
Point-to-point-protocol statistics
Statistics from the TCP/IP area
Statistics from the IP router
Remote configuration statistics
DSL connection statistics
Statistics relating to the packets in the queues of the individual
modules
Connection information for each interface
Information on the last connection for each interface
Statistics on the last 100 connections
Information of the status of the individual channels.
Time module information
Deletes all values in the substatistics except tables
