6 Installation
You will find a number of LEDs as display elements on the front panel.
This LED flashes once when the power supply is switched on. After the self-test, either
Power/Msg
an error is output by a flashing light code or the device starts and the LED remains lit.
Off
red
red
red
DSL-Rx/Tx This yellow LED shows that data is moving on the DSL connection.
DSL-Link This green LED shows that the Ethernet connection between ELSA LANCOM DSL/10
Office and the DSL terminal is operating properly.
DSL-Chan This LED shows the status of the DSL connection to the switching center:
Off
red
green
The connection is active and incurring charges so long as the 'DSL-Chan' LED is green!
These LEDs show the corresponding network controller status:
LAN-tx, -rx,
LAN-Coll, -Link
LAN-rx/tx
LAN-FDpx, -Fast
LAN coll
LAN-Link
LAN-FDpx
LAN-Fast
ELSA LANCOM DSL/10 Office
Device off
1 x short Boot procedure (test and load) started
flashing Display of a boot error (flashing light code)
Device ready for use
ELSA LANCOM DSL/10 Office has not requested a login at the switching center
ELSA LANCOM DSL/10 Office has requested a login at the switching center; it is logging in
It has successfully logged in and is connected to the provider
yellow Data packet sent from the device to the LAN or vice versa
red Sending collision
green Connection to LAN is established and ready
green Router is transmitting and receiving data simultaneously
green ELSA LANCOM DSL/10 Office is operating at 100 Mbit
