R8 Description of the menu options

Status/PPP-statistics

Within the PPP statistics, the states of individual subprotocols of the PPP are managed
separately for each interface. However, statistics relating to the frames transmitted for
individual subprotocols are maintained only in joint statistics. Consequently, the Status/
PPP-statistics menu has the following layout:
/PPP-statistics
PPP-phases
LCP-statistics
PAP-statistics
CHAP-statistics
IPCP-statistics
CCP-statistics
Rx-options
Tx-options
Delete-values
The PPP statistics provide detailed information on the phases of a PPP negotiation,
particularly in the event of connection problems with external products. It provides
important information for error diagnosis.
PPP-phases For each available interface, the Status/PPP-statistics/PPP-phases option provides
a list of the current states of PPP protocol negotiation. The table maintained here has
the following layout:
Ifc
Ch01
Below is a detailed description of the meaning of each field:
Ifc
Phase to
LCP
IPCP
CCP
ELSA LANCOM DSL/10 Office
Running status displays
Statistics relating to the status of PPP protocol negotiation for
each interface
Displays PPP/LCP statistics
Displays PPP/PAP statistics
Displays PPP/CHAP statistics
Displays PPP/IPCP statistics
Displays PPP/CCP statistics
Displays the LCP and IPCP information received
Displays the LCP and IPCP information sent
Deletes PPP statistics.
Phase to LCP IPCP
DEAD Initial Initial
Designates the associated channel.
Indicates the current phase of the PPP. The possible values are AUTHENTICAT,
NETWORK and TERMINATE.
Status of the 'Link Control Protocol' subprotocol. The possible values are: Initial,
Starting, Stopping, Stopped, Closing, Closed, ReqSent, AckRcvd, AckSent
and Opened.
Similarly to 'LCP', displays the status of the 'IP Control Protocol' subprotocol.
Similarly to 'LCP', displays the status of the 'Compression Control Protocol'
subprotocol.
CCP
Initial
