The current PPP phases are shown under Status/PPP-statistics/PPP-phases. As
specified above, these phases are the idle (Dead), ready (Establish), access parameter
verification (Authenticate) and network phase (Network). In the substatistics, the frames
exchanged are encrypted separately by type and quantity.
Status/PPP-statistics/LCP-statistics
The LCP (Link Control Protocol) negotiates the basic features of the PPP connections. The
LCP frames exchanged during PPP negotiation are recorded in statistics and displayed by
type and quantity. If the LCP does not change to the OPEN state for a connection, these
statistical values provide information on errors that occurred during the initial phase of
PPP negotiation. Below is a detailed description of the meanings of the parameters for
these statistics:
Rx-errors
Rx-discarded
Rx-config-request
Rx-config-ack.
Rx-config-nak.
Rx-config-reject
Rx-terminate-request
Rx-terminate-ack.
Rx-code-reject
Rx-protocol-reject
Rx-echo-request
Rx-echo-reply
Rx-discard-request
Tx-config-request
Tx-config-ack.
Tx-config-nak.
Tx-config-reject
Tx-terminate-request
Tx-terminate-ack.
Tx-code-reject
Tx-protocol-reject
Tx-echo-request
Tx-echo-reply
Tx-discard-request
Delete-values
Description of the menu options
Number of faulty PPP packets received
Number of PPP packets discarded
Number of configure request packets received for LCP
Number of configure acknowledge packets received for LCP
Number of configure negative acknowledge packets received
Number of configure reject packets received for LCP
Number of terminate request packets received for LCP
Number of terminate acknowledge packets received for LCP
Number of code reject packets received for PPP
Number of protocol reject packets received for PPP
Number of echo request packets received for LCP
Number of echo response packets received for LCP
Number of discard request packets received for LCP
Number of configure request packets sent for LCP
Number configure acknowledge packets sent for LCP
Number of configure negative acknowledge packets sent
Number of configure reject packets sent for LCP
Number of terminate request packets sent for LCP
Number of terminate acknowledge packets sent for LCP
Number of code reject packets sent for PPP
Number of protocol reject packets sent for PPP
Number of echo request packets sent for LCP
Number of echo response packets sent for LCP
Number of discard request packets sent for LCP
Deletes LCP statistics
