Appendix
Technical data
Functions
IP router, DHCP server, DHCP client
LAN connection
Ethernet IEEE 802.3, 10/100Base-T (RJ45, node/hub switch), auto-sensing,
full duplex operation
Network protocols
PPP via Ethernet, ARP, PROXY ARP, IP, ICMP, UDP, TCP, TFTP, RIP-1, RIP-2, DHCP,
DNS
Filter possibilities
Source and target filters for networks, protocols and ports; separate WAN and
LAN
WAN interface
Ethernet IEEE 802.3, 10Base-T (RJ45)
Charge monitoring
Maximum charges or connection time for a preset period can be set
Security and
PAP and CHAP, authentication mechanisms in PPP; filter options in IP mode;
firewall functions
configuration protection with access lists and password; IP masquerading
IP masquerading
IP address and port implementation using a single IP address, static/dynamic
(NAT/PAT)
IP address assignment via PPP or DHCP, masking of TCP, UDP, ICMP, FTP;
DNS forwarding; inverse masquerading Intranet IP services such as web server
Management
V.24/V.28 outband interface (8-pin mini-DIN), TFTP configuration and firmware
upload, SNMP management via SNMP v.1 or v.2, WAN or LAN accesses can be
activated separately, diagnosis outputs for protocols and interfaces, diagnosis
tools, status display ELSA LANmonitor
Operating security
Hardware watchdogs, regular self-testing, FirmSafe concept for remote software
upgrades
Statistics
LAN and WAN packet counters; error, connection and charge counters, timer
Display/operation
LEDs for LAN, WAN and device status
Power supply
12 VA with AC adapter for 230 V, 12 VA
Environmental
Temperature: 5-40°C, humidity: 0-80%, non-condensing
conditions
Dimensions and
Rugged metal case, connections on rear panel; dimensions
design
158 x 40 x 125 mm (W x H x D)
Package contents
Power adapter, cable for outband interface, two LAN twisted-pair cables,
detained documentation and ELSA LANCOM CD
ELSA LANconfig, ELSA LANmonitor for status display, terminal program
ELSA-ZOC
Approvals:
in preparation: Germany, Switzerland and all other EU countries
Service
Warranty: 6 years
Support: by Infoline and Internet; test inputs
Appendix
ELSA LANCOM DSL/10 Office
41
