Status/Dsl-Statistics/Pppoe-Statistics - ELSA Lancom DSL/10 Office Manual

/DSL-statistics
DSL-tx-errors
DSL-Rx-no-conn.
DSL-NIC-errors
DSL-queue-packets
DSL-queue-errors
DSL-rx-bytes
DSL-tx-bytes
DSL-rx-unicast
DSL-tx-broadcast
DSL-tx-unicast
Connection established
PPPoE-statistics
Delete-values

Status/DSL-statistics/PPPoE-statistics

Statistics on establishing the connection with PPP via Ethernet are displayed here. If a
connection to the Internet provider cannot be established, this information will assist the
error search.
/PPPoE-statistics
Tx-PADI
Rx-PADO
Tx-PADR
Rx-PADS
Tx-PADT
Rx-PADT
Tx-potocol
Rx-protocol
Tx-data
Rx-data
Description of the menu options
DSL terminal statistics
Number of packets with defective content sent to the
DSL interface
Number of packets without logical connections received at
the DSL interface
Number of internal errors at the DSL interface
Number of packets still to be sent
Number of packets discarded due to a lack of buffers
Number of characters received via the DSL interface
Number of characters sent via the DSL interface
Number of packets directed directly to the LANCOM
Number of broadcasts sent to the DSL interface
Number of packets sent directly to the AC
Display of link status of the DSL connection
Statistics on special PPP over Ethernet packets
Deletes DSL statistics
Statistics on special PPP over Ethernet packets
Number of PPP Active Discovery Indications sent (start of
negotiation)
Number of PPP Active Discovery Offers received (AC offers)
Number of PPP Active Discovery Requests sent
(AC requests)
Number of PPP Active Discovery Session Confirmations
received (AC session confirmation)
Number of PPP Active Discovery Terminates sent (end of
session)
Number of PPP Active Discovery Terminates received (end
of session)
Number of protocol packets sent
Number of protocol packets received
Number of user data packets sent
Number of user data packets received
ELSA LANCOM DSL/10 Office
R21
