Status/Connection-statistics

This menu allows you to display connection times and other useful information related
to DSL port utilization.
For each available interface, the Status/Conn.-statistics menu option provides
statistics on the connections established via this interface. The table maintained here
has the following layout:
Ifc Connection
Ch01 0
Below is a detailed description of the meaning of each field:
Ifc Designates the associated channel.
Connection Indicates the number of connections to the particular channel.
Errors Indicates the number of connection errors.
Con.-Time Indicates the period of time the current connection has existed. If no connection
exists, "No-connection" is output.

Status/Info-connection

The menu item Status/Info-connection has additional information on the current
connection status (logical remote station etc.) for every available interface. The table
maintained here has the following layout:
Ifc Status
Ch01 Ready
Below is a detailed description of the meaning of each field:
Ifc Designates the associated channel.
Status Indicates the status of the particular connection.
The possible values are: initialization, setup WAN, ready, establish PPPoE,
protocol, connection, release
Device-name Indicates the logical name of the remote station (if it can be detected).
SH-time Indicates the short timeout for the connection.

Status/Remote-statistics

This table shows the last hundred connections of the ELSA LANCOMs with information
on the remote station.
Description of the menu options
Errors Con.-Time
0 No connection
Device-name SH-time
0
