iRay Technology Venu 1012X Calibration Manual

10x12 tethered
Hide thumbs
Table of Contents

Advertisement

Quick Links

iRay 10x12 Tethered Calibration Guide
April 2, 2018
Version 1.01
20/20 Imaging, a division of Konica Minolta Healthcare Americas, Inc.
819 Virginia Rd. Ste. A – Crystal Lake, IL 60014
© 2017 Konica Minolta, Inc. All Right Reserved.
866-734-6234 ext. 1 – support@2020imaging.net
KON-000022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Venu 1012X and is the answer not in the manual?

Questions and answers

Related Manuals for iRay Technology Venu 1012X

Summary of Contents for iRay Technology Venu 1012X

  • Page 1 iRay 10x12 Tethered Calibration Guide April 2, 2018 Version 1.01 20/20 Imaging, a division of Konica Minolta Healthcare Americas, Inc. 819 Virginia Rd. Ste. A – Crystal Lake, IL 60014 © 2017 Konica Minolta, Inc. All Right Reserved. 866-734-6234 ext. 1 – support@2020imaging.net KON-000022...

  • Page 2: Table Of Contents

    iRay 10x12 Tethered Calibration Guide Table of Contents SPECIAL NOTE ..............................3 PRE-PREPARATION ............................3 CALIBRATION ..............................3 ............................3 ANEL LIGNMENT ..........................4 ETECTOR REPARATION PXS710D ( ) ..........................6 IF APPLICABLE ............................6 ALIBRATION .............................7 EFECT ALIBRATION ..........................9 INAL ONFIGURATIONS GENERAL INFORMATION, OPERATION, MAINTENANCE ................. 11 20/20 Imaging, a division of Konica Minolta Healthcare Americas, Inc.

  • Page 3: Special Note

    iRay 10x12 Tethered Calibration Guide 1 Special Note Please read and review the iRay-Venu1012X User Manual before proceeding with this guide. By proceeding, you agree that you have read and understand all content within that User Manual. The iRay-Venu1012X User Manual is included with the unit and can also be found on the 20/20 Imaging website. 2 Pre-Preparation 1.

  • Page 4: Idetector Preparation

    iRay 10x12 Tethered Calibration Guide 3.2 iDetector Preparation 1. Open the iDetector shortcut from the desktop. If nothing occurs when opening, ensure Microsoft Visual C++ 2013 32-bit is installed on the PC. 2. Highlight DEFAULT and click Connect. 3. Select the Acquire tab and deselect the Defect, Gain, and Offset options (in that order). 4.
  • Page 5 iRay 10x12 Tethered Calibration Guide 5. Click the arrow next to the ‘Start the journey of Calibration’ message. 6. Immediately click Skip on the Offset Map Generating window. NOTE: If you do not click Skip within two seconds, you will have to wait for the Offset Map to be generated.

  • Page 6: Pxs710D (If Applicable)

    iRay 10x12 Tethered Calibration Guide 3.3 PXS710D (if applicable) 1. Open the PXS710D shortcut from the desktop. NOTE: If you receive an error; in the file menu, select Config > Options. Select the Serial tab and set the corresponding COM port (COM1 is default). Click Save. *If a straight serial cable is utilized, select COM1.

  • Page 7: Defect Calibration

    iRay 10x12 Tethered Calibration Guide 3. Adjust dose until the message states, Center Average is expected. After receiving the correct dose, click NEXT and then click PREP to continue with each exposure. 4. Once the gain calibration is, click NEXT and click NEXT again to complete the Gain Calibration. 3.5 Defect Calibration 1.
  • Page 8 iRay 10x12 Tethered Calibration Guide 2. Click PREP and take an exposure for each progress step. 3. Adjust dose until the message states, Center Average is expected. After receiving the correct dose, click NEXT and then click PREP to continue with each exposure. 4.

  • Page 9: Final Configurations

    iRay 10x12 Tethered Calibration Guide 5. Once the defect calibration is, click NEXT and click NEXT again to complete the Gain Calibration. Close the window once the Calibration Finished message is displayed. 3.6 Final Configurations 1. Return to the Calibration tab. Select the Gain tab and then click ReadStatus. Highlight option 1 and click SelectFile.
  • Page 10 iRay 10x12 Tethered Calibration Guide 4. Type 1 in the FileIndex filed and click OK. 5. The following message will display after the gain file has been downloaded to the panel. Click 6. Select the Defect tab, then click ReadStatus and highlight option 1. Click SelectFile. This will change the option one status to enable.

  • Page 11: General Information, Operation, Maintenance

    iRay 10x12 Tethered Calibration Guide 9. Type 1 in the FileIndex filed and click OK. 10. The following message will display after the gain file has been downloaded to the panel. Click 11. Enable the Offset, Gain, and Defect options (in that order). Select the HWDefect, HWGain, and HWPostOffset options.
