Fisher Engineering SNOWPLOW Owner's Manual page 78

DETACHING SNOWPLOW FROM VEHICLE & STORAGE
Detach HT Series™ Blade
Pin Release
Handle
ON
Jack
(lowered)
Lit. No. 72446, Rev. 05
NOTE: Place electrical plugs in storage
position. The driver-side and center plug
on 3-plug electrical systems are joined for
storage. The passenger-side and 2-plug
Headlamp Bracket
systems are equipped with plug covers.
Pushplate
Attachment
Arm
Connecting Pin
Jack Lock
79
Pin
Release
Handle (raised)
Jack
(raised)
Jack Lock
