GETTING TO KNOW YOUR SNOWPLOW

System Capacity

EZ-V Snowplows and HS Compact Plows
®
• Insta‑Act Unit Reservoir .............. 1‑3/4 quarts
®
• Insta‑Act System Total .................. 2‑1/8 quarts
All Other Blades
• Insta‑Act Unit Reservoir ................ 1‑3/4 quarts
• Insta‑Act System Total .....2‑3/8 to 2‑3/4 quarts
Lit. No. 72446, Rev. 05

Pump Motor Specifications

Straight Blades
12V DC with +/– Connection
2200–2300 psi Pump Relief Valve
4000 psi Angling Relief Valve
4.5" dia 1.5 kW Motor
0.000477 gal/rev Pump
Hydraulic Hose 1/4 SAE 100R1 and 3/8 SAE 100R17
HT Series™ Blades
12V DC with +/– Connection
1600–1700 psi Pump Relief Valve
4000 psi Angling Relief Valve
3" dia 0.8 kW Motor
0.000477 gal/rev Pump
Hydraulic Hose SAE 100R1
27 November 15, 2020
