Control Functions
RAISE, LOWER, FLOAT, Angle
ON/OFF
RAISE
SCOOP
1
L
3
WING
IN/OUT
LOWER
Moving the control lever straight up and down or
from side to side on the control body will result in
the blade movements described in the following
tables.
Lit. No. 72446, Rev. 05
OPERATING YOUR SNOWPLOW
FLOAT
FLOAT Light
(green)
RETRACT
2
R
4
WING
IN/OUT
Function Description of Operation
Move the control lever toward the top of the
RAISE control body to raise the blade and cancel
the FLOAT mode.
Move the control lever toward the bottom
of the control body to lower the blade.
LOWER
Release the lever to stop the blade at the
desired height.
Move the control lever to the LOWER
position and hold 3/4 second to activate
this mode. The FLOAT light in the upper
right corner of the control face will
illuminate. The blade will lower to the
ground surface and follow the contour of
the surface as it dips or raises. Function
FLOAT
†
does not time out; however, control will
shut down after 20 minutes of nonuse.
Move lever to the RAISE position
momentarily to cancel FLOAT. Angling
left or right will not interrupt (pause) the
FLOAT function.
FLOAT mode activates immediately when one‑touch FLOAT
†
feature is enabled. See "One‑Touch FLOAT" in this section
for more information.
