Function Description of Operation
Press this button to extend both wings
SCOOP
forward into the scoop position.
Press this button to draw both wings into
RETRACT
the fully retracted/vee position.
Press this button on the left side of the
control to move the left wing. The first
time the button is pressed after the
control is turned ON or another function
L WING
is used, the wing will extend. Repeated
use of the same button, without using
another function, results in movement in
the opposite direction from the previous
movement.
Press this button on the right side of
the control to move the right wing. The
first time the button is pressed after the
control is turned ON or another function
R WING is used, the wing will extend. Repeated
use of the same button, without using
another function, results in movement in
the opposite direction from the previous
movement.
Lit. No. 72446, Rev. 05
OPERATING YOUR SNOWPLOW
SECURITY GUARD™ System (1, 2, 3, 4)
The four round buttons located to the left and
right of the LOWER and RAISE buttons will
also operate the SECURITY GUARD system (if
equipped). See "SECURITY GUARD System" in
this section for more information.
Function Description of Operation
Press this button on the left side of the
control to move the left wing. The first time
the button is pressed after the control is
turned ON or another function is used, the
L WING
wing will extend. Repeated use of the same
button, without using another function,
results in movement in the opposite
direction from the previous movement.
Press this button on the right side of the
control to move the right wing. The first time
the button is pressed after the control is
turned ON or another function is used, the
R WING
wing will extend. Repeated use of the same
button, without using another function,
results in movement in the opposite
direction from the previous movement.
