Summary of Contents for Fisher Engineering Minute Mount 2 SD Series
Page 1
27775, 28069 57000, 57000‑1, 57000‑3 Fisher Engineering July 15, 2020 50 Gordon Drive, Rockland, Maine 04841‑2139 • www.fisherplows.com Lit. No. 49591, Rev. 05 SD Series Snowplows Installation Instructions CAUTION Read this document before installing the snowplow. CAUTION See your FISHER outlet/website for specific ®...
27775, 28069, 57000, 57000‑1, 57000‑3 SAFETY DEFINITIONS WARNING/CAUTION AND INSTRUCTION LABELS WARNING Become familiar with and inform users about the Indicates a potentially hazardous situation warning labels on the back of the blade and the that, if not avoided, could result in death or instruction label on the headgear.
27775, 28069, 57000, 57000‑1, 57000‑3 SAFETY PRECAUTIONS HYDRAULIC SAFETY Improper installation and operation could cause WARNING personal injury and/or equipment and property damage. Hydraulic fluid under pressure can cause skin Read and understand labels and the Owner's Manual injection injury. If you are injured by hydraulic before installing, operating, or making adjustments.
27775, 28069, 57000, 57000‑1, 57000‑3 FIRE AND EXPLOSION NOISE Airborne noise emission during use is below 70 dB(A) WARNING for the snowplow operator. Gasoline is highly flammable and gasoline vapor is explosive. Never smoke while VIBRATION working on vehicle. Keep all open flames away from gasoline tank and lines.
Page 5
27775, 28069, 57000, 57000‑1, 57000‑3 HEADGEAR TO A‑FRAME ASSEMBLY 5. Align the holes in the headgear assembly with the middle hole in the A‑frame assembly. Attach the A‑frame to the headgear with two step pins NOTE: For easier assembly and installation, and 1/4"...
Page 6
27775, 28069, 57000, 57000‑1, 57000‑3 A‑FRAME TO BLADE ASSEMBLY 5. Align the angle ram rods with the angle ram holes on the blade, and attach using two 1" x 4‑3/4" clevis pins, installed from the top. 1. Align the pivot‑pin hole on the A‑frame with the Secure with 1/4"...
27775, 28069, 57000, 57000‑1, 57000‑3 HYDRAULIC UNIT WARNING To prevent accidental movement of the blade, WARNING always turn the control OFF whenever the snowplow is not in use. The power indicator Keep 8' clear of the blade when it is being light will turn OFF.
Page 8
27775, 28069, 57000, 57000‑1, 57000‑3 HEADLAMPS 6. Secure the snowplow harnesses and wires to the headgear with cable ties as shown. WARNING Cable Your vehicle must be equipped with snowplow Ties headlamps and directional lights. Headlamps, hardware, and instructions are found in the headlamp box.
27775, 28069, 57000, 57000‑1, 57000‑3 FINAL ADJUSTMENTS 3. Remove and retain the U‑bolt and locknuts securing the lift chain on the passenger's side of the A‑frame. Reposition the U‑bolt in the chain so WARNING that the chain is the same length as the chain on Keep 8' clear of the blade when it is being the driver's side.
27775, 28069, 57000, 57000‑1, 57000‑3 Lift Chain (DS) Link #1 Connecting Link Spring Driver‑Side U‑Bolt Center U‑Bolt With the snowplow attached to a properly ballasted vehicle, make one of the following adjustments: If there is not enough slack in the lift chain, there will be difficulty getting the connecting pins to engage the vehicle pushplates while pushing back on the headgear.
Page 11
27775, 28069, 57000, 57000‑1, 57000‑3 VEHICLE LIGHTING CHECK With the headlamp switch OFF, activate the vehicle DRLs. 1. Verify the operation of all vehicle front lighting Snowplow lighting harness DISCONNECTED: prior to connecting the snowplow harness. • Vehicle DRLs should be ON. •...
Page 12
27775, 28069, 57000, 57000‑1, 57000‑3 Fisher Engineering reserves the right under its product improvement policy to change construction or design details and furnish equipment when so altered without reference to illustrations or specifications used. Fisher Engineering or the vehicle manufacturer may require or recommend optional equipment for snow removal.
