Function Description of Operation
Straight blades: Move the control lever
straight to the left to angle the blade left.
L
All others: With wings in a straight line,
(Angle
move the control lever straight to the left to
Left)
move both wings to the angle left position.
The left wing retracts while the right wing
extends (XtremeV™, XV2™, EZ‑V
Straight blades: Move the control lever
straight to the right to angle the blade right.
R
All others: With wings in a straight line,
(Angle
move the control lever straight to the right to
Right)
move both wings to the angle right position.
The right wing retracts while the left wing
extends (XtremeV™, XV2™, EZ‑V
Lit. No. 72446, Rev. 05
OPERATING YOUR SNOWPLOW
).
®
).
®
SCOOP/RETRACT Blade and WING Positions
XtremeV, XV2, EZ-V, and XLS™ Blades
Moving the control lever from the center position
toward the word SCOOP or RETRACT on the face
of the control body will cause both wings to move
at the same time into the following blade positions.
Moving the control lever from the center position
toward the words WING IN/OUT, on either side of
the face of the control body will cause either wing
to move independently of the other as described in
the following table.
Function Description of Operation
Move the control lever toward the word
SCOOP SCOOP on the control face to extend both
wings forward into the scoop position.
Move the control lever toward the word
RETRACT RETRACT on the control face to draw both
wings into the fully retracted/vee position.
