12.2 DMX-CHANNELS

The following DMX channels are used to control the X2 Wave Flamer in Easy DMX mode:
DMX-channels
Channel 1 (Starting address + 0)
Channel 2-70 (according to Wave Flamer
settings)
12.2.1 CHANNEL 1: MODE (STARTING ADDRESS)
The first DMX channel is the usage mode. Here you can set the whether the device should be armed
with a DMX value of 50-200. The other values designate the test mode. Note that you can only ignite
in armed mode.
DMX value
Mode Test mode
12.2.2 CHANNEL 2-70: SINGLE IGNITION / SEQUENCE
DMX channels 2-70 are used after turning the device armed via channel 1, to make single ignitions or
sequences. As soon as a DMX channel is set 255, the chosen channel number from the list of
sequences will ignite. After ignition, the DMX channel must be reset to 0 before the next ignition. You
can only ignite one sequence at a time. To ignite the different variants, we recommend the usage of
the flash buttons of your DMX controller.
DMX value
Mode Reset (after ignition)
Usually only DMX channels 2-16 have predefined sequences.
Edit DMX settings
0 to 49
When switched armed, pressure will start to build in teh
Wave Flamer. This first procedure will take about 20
seconds, during which the device won't react to ignition
Ignition variants (DMX channels 2-70)
0
Further ignitions must be assigned to an individual DMX
channel on the Wave Flamer.
M-DMX: Modus
Mode
Single ignition or sequence
Mode
50 to 200
Armed mode
commands.
1-254
No function
ON
201 to 255
Test mode
47
255
Ignition
