3.3 HEAD VARIANT WITHOUT INTERNAL PUMPING UNIT (FRONT)

8
Components of the X2 Wave Flamer
1
Key switch
2
Display and usage buttons
3
Status-LEDs
4
Antenna socket
5
Programming socket
6
DMX-connector
1
7
8
9
2
3
5
10
7
ON/OFF switch (Power)
8
Fuze 12VDC
9
Connector for external pumping unit
10
Power connector 100-230VAC Neutrik True-1
11
Fuze 230VAC
4
6
