4 MENU ITEMS

The menu of the Wave Flamer can be opened in test-mode with the Mode/OK button. The navigation
through the menu is done with the Plus and Minus button. The Mode/OK button allows you to confirm.
Exiting the menu can be done with the Test/ESC button.
The menu will close automatically after a minute of inactivity.

4.1 MAIN MENU

Menu
ID and Box number
Pressure
Mains supply informations
Type and Showname
Check and Lines
Sec-Key and Frequency
Power and Timeout
Position min/max
View AUTOSHOW list
Edit Wave Flamer settings
see sub chapter
Edit DMX settings
see sub chapter
Systemtest start?
see sub chapter
Pump and vent
Software version
Group BOX
