Explo X2 Wave Flamer Manual page 22

Since all devices with the same box number will ignite at the same time, this allows for easy setting of
device groupings for manual ignitions.
4.2.20.1 EXAMPLE
Main Box
Group Box 1
Group Box 2
Group Box 3
In the example above, every Wave Flamer has its own main box. This is the standard box number of
the device, which allows for manual and automatic ignitions.
In addition, group boxes can be assigned, allowing for manual control. This way, ignitions of box 15,
will activate all devices at the same time. Box number 16 will only activate device A and B.
22
4.2.21 M-SET: PUMP
Allows you to change between an internal and external pumping unit. This option is currently only
used to differentiate between the X2 Wave Flamer and the X2 Wave Flamer Head. The standard
setting for the X2 Wave Flamer is "INSIDE", wheras for the Head it is "OUTSIDE". The standard
should not be changed.
4.2.22 M-SET: PRESSURE
Allows you to change the pressure slightly to level slight differences in flame height. You can select
between "LOW", "MID" and "HIGH". The current software only allows for the use of "MID", as the other
two options are currently unused.
A
10
15
16
18
Group boxes can only be used for manual control, and can't
be used in automated shows.
B C
11
15
16
17
12
15
17
18
