11.1 PREPARING THE DMX-512-MODE

Check the settings for the DMX starting address. This is the address of the first channel used:
Menu
To activate the DMX 512 mode, you must select the DMX 512 setting in the Protocol menu:
Menu
Next, DMX control must be activated:
Menu

11.2 DMX-CHANNELS

The following 6 DMX channels are used to control the X2 Wave Flamer in DMX 512 mode. Since the
full spectrum of the channels is used (0-255), the Master switch of the DMX controller should be set to
42
100%.
DMX channels (DMX 512)
Channel 1 (Starting
address + 0)
Channel 2 (Starting
address + 1)
Channel 3 (Starting
address + 2)
Channel 4 (Starting
address + 3)
Channel 5 (Starting
address + 4)
Channel 6 (Starting
address + 5)
Edit DMX settings
Edit DMX settings
Edit DMX settings
Angle
Speed
Ignition
Opening time
Programm
Mode
M-DMX: Startadresse
M-DMX: Protocol
M-DMX: Modus
Example DMX value
128 – Mid position (0°)
0 – maximum speed
0 – no ignition
255 – Ignition
0 – Standard value
0 – Test-mode
128 – Armed-mode
255 – Test-mode
DMX 512
ON
