- Page 1 Explo Zündtechnik GX3 Power Flame Manual v1.3 as of November 2016 Explo Zündtechnik Harald Kulterer Völkermarkterstrasse 240 9020 Klagenfurt am Wörthersee Austria Tel: +43 (0) 463 / 32 2 45 Fax: +43 (0) 463 / 32 2 45 75 Mobil: +43 (0) 664 / 51 007 51 www.explo.at...
- Page 2 ~The Team of explo • General Overview/Description of components • Overview The GX3 Power Flame is used to create Flames of extreme heights. A pilot flame ignites gas, which is stored and ejected from a pressure tank with 8bar, via radio control.
- Page 3 • Overview of components...
- Page 4 Pressure readout The pressure is also monitored with a processor. It shows the actual pressure currently in the tank. Small differences are possible in the display. • Usage of the GX3 Power Flame • General information for usage • Usage of Campinggas (Propane-Buthane mix) The general safety precautions for the usage of gas, as well as the directions given by the safety data sheet of the used gas are to be adhered.
- Page 5 Great leak • Overpressure valve is open • Control via radio The control of the GX3 Power Flame can only be made via radio or DMX. The Box number can be altered in the menu. Channel Function Pilotflame (1 Sek)
- Page 6 VENT (Careful, the gas will not be ignited) STOP recharge routine START recharge routine Control via DMX • Channel Function 1 (0-255) Ignition ≤ 253 = no ignition 254 and 255 = Ignition 2 (128) Opening time 0 = 0,5 sec 255 = 2,5 sec 3 (0-128-255) Status...
- Page 7 Attachment • In the attachments you can find the current Conformity declaration.
- Page 8 The sole responsibility for issuing this conformity declaration lies with the manufacturer. Item of declaration Name: Flamenprojector Type and trade name: GX3 Power Flame Modell: GX3 Power Flame v1.0 Seialnumber: Function: The Flame projector "Power Flame" uses an integrated pressure tank to eject propane-/buthane gas (taken from 1-2 10Kg bottles) with 7bars of pressure.
