15 TECHNICAL DATA

X2 Wave Flamer
Measurements
Weight
Power supply
Casing
Fuel
Radio range
Swivel radius
Effect height

16 ACCESSORIES (AVAILABLE SEPARATELY)

Optional accessories for the X2 Wave Flamer
Power connection cable
Tripod
5m nozzle
Flight-Case
Dolly for Flight-Case
Emergency shut off
Tool to switch nozzles
Bootloader cable
Rain protection
Angle blockers

17 INFORMATIONS FOR USEABLE FLUIDS

Bioethanol 99%, Isopropanol 99% (IPA), ISOPAR (G, H, L, M)
560x335x365mm
27kg (empty Tank)
100VAC-230VAC / 350W
Stainless steel
Isopropylalcohol, Bio-Ethanol, ISOPAR™ / We recommend adding 2cl castor oil
per 10L fluid
800m
-105° to 105°
10m (optional 5m nozzle available)
To lead power through to the next device. Available in all lengths.
Tripod for the X2 Wave Flamer. Diameter 35mm / 50kg load bearing.
Nozzle for reduced flame height (4-5m).
Flight Case for safe transportation of the Wave Flamers.
Dolly for up to three Flight-Cases (stacked).
Emergency shut off switch for immediate interruption of the power supply.
Tool to easily change the nozzles of the Wave Flamer. 14mm socket nut long.
Programming cable to update the devices firmware.
Protective cover to protect the front panel from water.
Mechanical angle blockers for the X2 Wave Flamer.
To lubricate the system, we recommend adding 10-20mL
castor oild per 10L canister.
Recommended fluids are:
If non recommended fluids are used (especially coloured
fluids), damages to the system may occur, leading to a
voiding of the guarantee.
