4.3 Control via DMX 512

Optionally, the X2 Wave-Flamer can be controlled by DMX 512. 6 DMX channels are needed.

4.3.1 DMX-Channels

The followeing 6 DMX-Channels are needed for the X2 Wave-Flamer:
Channel 1: Angle (Starting adress)
Channel 2: Speed (Starting adress +1)
Channel 3: Ignition (Starting adress +2)
Channel 4: Opening Time (Starting adress +3)
Channel 5: Program (Starting adress +4)
Channel 6: Mode (Starting adress +5)
4.3.1.1 Channel 1: Angle (Starting adress)
The angle is the first channel (=starting adress). It defines to which angle the head of the Flamer will
move to. The angle can be chosen anywhere between -105° to +105° (DMX-value 0 to 255).
Since the DMX-value itself can only be a whole number, some angles must be rounded up.
The calculated DMX-value for an angle of 0° is 127.5 (rounded up 128). Using this value, the following
formula can be used to calculate all other angles ∡ (in degrees). Please always note the prefix of
the angle.:
DMX Value = 127,5 + (∡ • 1,2143)
To calculate a DMX value in percent, the following formula must be used:
% Value = DMX value • (100/255)
Below you can find some examples for the DMX value of an angle.
Channel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Angle
-105°
-90°
-75°
-60°
-45°
-30°
-15°
15°
30°
45°
60°
75°
90°
105°
DMX
DMX (%)
0
18
36
54
73
91
109
128
146
165
183
201
219
237
255
0%
7%
14%
21%
28%
35%
42%
50%
57%
64%
71%
78%
85%
92%
100%
