5.2 DEFINITION POSITIONS

Contrary to the control via DMX, not considering flame waves, only certain angles can be controlled
via radio. Overall, a spectrum of 210° (±105°) can be selected. This range has been separated into 15
positions, with a difference of 15° between each for radio control. These 15 positions have been
numbered from 1-15, and the middle, vertical position (Position 8) has been defined as 0°. The
following graphic shows the single positions as viewed from the audiences side.

6 PLANNING AN PREPARING A SHOW

A successful show begins with planning. We recommend giving some thought to these points:
Planning checklist
Is the use of the X2 Wave Flamer allowed at the location?
Can the neccessary safety distances be adhered to?
How many X2 Wave Flamers can and do I want to use?
Which flame height do I want and can I use (Selecting the nozzle!)
What fluid do I wish to use?
Optional: Planning an automated show (only for radio control).
Nothing is more frustrating than a X2 Wave Flamer whose fluid or cable has been forgotten in storage.
So these points should be checked before driving to the show location:
25
