- Page 1 Quick Start Guide BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router...
- Page 3 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router ❖ PLEASE READ THE QUICK START GUIDE AND FOLLOW THE STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER MANUAL.
- Page 4 Insert the mini SIM card (2FF) with the gold contact facing down. SIM Card Slot Push the mini SIM card (2FF) inwards to eject it * Power off the BEC 4700AZ before inserting or removing the SIM card(s) Green Wireless connection established 2.4GHz WIFI LED...
- Page 5 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router PORT & LED MEANING Green RSSI greater than -69 dBm. Excellent signal condition Green Flashing Quickly RSSI from -81 to -69 dBm. Good signal condition LTE LED Orange Flashing Quickly RSSI from -99 to -81 dBm. Fair signal condition...
- Page 6 Quick Start Guide Hardware Overiew (BEC 4700A) PORT & LED MEANING WIFI Antenna Connectors Screw the supplied 2.4GHz antennas onto the antenna connectors on both sides. (2.4GHz) After the device is powered on, press it 6 seconds or above: to restore to factory default settings (this is used when you cannot login to the router, e.g.
- Page 7 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router PORT & LED MEANING Green System is up and ready Power LED Boot failure Green IP connected; WAN connection is ready Internet LED IP request failed Either in bridged mode or WAN connection is not available Use an outdoor Ethernet cable to connect to an Ethernet equipment.
-
Page 8: Mounting Kit Installation
Quick Start Guide Mounting Kit Installation Mounting Kit includes: 1. Articulation Pole x 1 M8 Nut x 1 2. T-formed Bracket x 1 3. M8x40 Screw Bolt x 1 Articulation Pole x 1 4. M8 Nut x 1 M8 Washer x 1 M6 Washer x 4 5. - Page 9 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router Attach the Articulation Pole to the Enclosure Attach the articulation pole to the back of the BEC 4700A/4700AZ ODU enclosure using the supplied M6 screws, M6 spring washers and M6x16 screws which are included in the mounting kit.
- Page 10 Quick Start Guide Note: The flexible mounting kit can be adjusted in multiple angles to align with the base station for higher efficiency. ∘ 45∘ ∘ 45∘...
- Page 11 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router Wall or Pole Mount Installation Mounting on Wall Fix the T-formed Bracket to the wall by using wood screws and Gyprock plugs. Wood / Gyprock Plug T-formed Bracket Wood Screw Mounting on a Pole between 1.5” to 2” (38.1~50.8mm) Attach the T-formed Bracket and the W-bar to the pole then use M6x60 bolts, M6 spring washers and M6 washers to fix the mounting kit onto the pole.
- Page 12 Attach the BEC 4700A/AZ Enclosure to the Pole Attach the articulation pole (the BEC 4700A/AZ ODU enclosure) to the T-formed bracket using the supplied M8 nut, M8 spring washer, M8 washer and M8x40 screw bolts. M8 Washer...
- Page 13 Attach the grounding wire to the BEC 4700A/AZ and tighten the screw. Position Adjustment Adjust the BEC 4700A/AZ ODU until it reaches the desire elevation and depression angle, then tight the M8 nut (see Attach the BEC 4700A/AZ Enclosure to the Pole for more information) Max. upward angle: 47∘...
- Page 14 Quick Start Guide Power Up and Initial Configuration of Your 4700A/AZ This section will instruct you on how to power up your BEC 4700A or BEC 4700AZ and perform setup configuration to get an internet connection. 1. Power up your BEC 4700A/AZ router...
- Page 15 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router Gland Rubber Body Ring Claw Sealing Step 3: ○ ○ ○ 3.1: Slide B , and C (sealing nut, claw, and rubber ring) over the Ethernet cable first ○ ○ 3.2. Slide and clip...
- Page 16 IMPORTANT: It is recommended to put the Gigabit PoE Injector on an UPS or Surge Protector. Use the supplied grounding wire to ground your BEC 4700A / 4700AZ ODU is REQUIRED! Powering via a PoE Switch: To connect the other of RJ-45 cable from the 4700A/ 4700AZ PoE_IN port to a PoE switch.
- Page 17 BEC 4700A / 4700AZ (4G/LTE) Wireless Outdoor Router Step 2: Slide the SIM card with the mental contacts (gold plate) facing down to the SIM slot then push it all the way in until you hear the clicking sound. It is recommended to use an industrial-grade SIM card.
- Page 18 Quick Start Guide Step 4: Login to your BEC 4700AZ the 4G/LTE Wireless Outdoor Router The default IP of modem is 192.168.1.254 with subnet 255.255.255.0. Make sure the attached PC to this router is in the same subnet and has an IP address in the range between 192.168.1.1 ~ 192.168.1.253.
- Page 19 2. Set up Your Internet Connection BEC 4700A (Wi-Fi AP) Step 1: After you have powered up your BEC 4700A device, connect the 4700A to your internet box/router or a fiber line, such a DSL / broadband / mobile router / network switch or FTTH, using a RJ-45 Ethernet cable.
- Page 20 Quick Start Guide New Password: assign a new, unique password Confirm Password: re-enter the new password again Next Step: click Next 3.2 Time Zone Configuration: Enable and select your Time Zone then click Continue to go on to the next step Time Zone: select your time zone Next Step: click...
-
Page 21: Troubleshooting
WAN settings again. Troubleshooting 1. None of the LEDs are on when you turn on the BEC Device. Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. -
Page 22: Fcc Statement
Quick Start Guide FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
