BEC AirConnect 8231 User Manual

5g cbrs outdoor router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Model
AirConnect
8231
®
:
Product: 5G CBRS Outdoor Router
teamsupport@bectechnologies.net | +1 972-422-0877
www.bectechnologies.net
Last revised: January 2021
Version release: v1.0
