Page 1: User Manual
User Manual RidgeWave 6900 4G/LTE Outdoor Router Last revised: July, 2017 Version release: v2.00... - Page 2 Copyright Notice Copyright@ 2017 BEC Technologies Inc. All rights reserved. BEC Technologies reserves the right to change and make improvement to this manual at any time without prior notice. No part of this document may be reproduced, copied, transmitted in any form or by any means without prior written permission from BEC Technologies, Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS COPYRIGHT NOTICE ........1 TABLE OF CONTENTS ........2 CHAPTER 1: INTRODUCTION ......1 .............. 1 NTRODUCTION TO YOUR OUTER & S ..............3 EATURES PECIFICATIONS ..............4 ARDWARE PECIFICATIONS ................5 PPLICATION IAGRAM CHAPTER 2: PRODUCT OVERVIEW ....6 .......... - Page 4 ................. 29 OGIN TO YOUR EVICE ....................31 TATUS Device Info ...................... 31 System Status ....................32 System Log ...................... 33 3G/4G-LTE Status..................... 34 Statistics ......................35 DHCP Table ...................... 38 ARP Table ......................38 VRRP Status ..................... 38 ..................39 UICK TART ..................
- Page 5 Auto Reboot ......................... 82 Diagnostics Tool ......................83 CHAPTER 5: TROUBLESHOOTING ....85 Problems with the Router ................85 Problem with LAN Interface ................85 Recovery Procedures ..................86 APPENDIX: PRODUCT SUPPORT & CONTACT ................. 87...
-
Page 6: Copyright Notice
100 (150) Mbps downlink and 50Mbps uplink. Lightweight, Compact and unobtrusive Design With multiple mounting options and a lightweight, it is easily to install the RidgeWave 6900 by single person. The RidgeWave 6900 also has a built-in passive Gigabit Power of Ethernet (GPoE) so both data and power can be sent from the unit. -
Page 7: Table Of Contents
Support a WEB GUI page to install this device quickly. With this wizard, simple steps will get you connected to the Internet immediately. Firmware Upgradeable Device can be upgraded to the latest firmware through the WEB based GUI. RidgeWave 6900 User Manual... -
Page 8: Features & Specifications
• Built-in NAT Firewall • Stateful Packet Inspection (SPI) • DoS attack prevention including Land Attack, Ping of Death, etc • Access control • IP&MAC filter, URL Content Filter • Password protection for system management • VPN pass-through RidgeWave 6900 User Manual... -
Page 9: Hardware Specifications
• SIM slot: (for the SIM card from Telco / ISP) • LED Indicators: Power, LAN (PoE), LTE, and Internet Physical Specifications • Dimensions (W*H*D): 8.5" x 7.5" x 3"(257mm x 227mm x 91mm) • Weight: 1.81kgs (4lbs) • IP-67 Grade Enclosure RidgeWave 6900 User Manual... -
Page 10: Application Diagram
Introduction Application Diagram RidgeWave 6900 User Manual... -
Page 11: Chapter 2: Product Overview
802.3at capable PoE injectors to connect with the RidgeWave 6900 ✓ It is mandatory to earth ground the RidgeWave 6900. Improper Attention grounding not only could damage the unit but also all eqiupments connected to it. -
Page 12: Device Description
RSSI from -99 to -81 dBm. Fair signal condition Flashing quickly Signal Strength Orange RSSI less than -99 dBm. Poor signal condition Indicator) Flashing slowly Orange No signal. 4G_LTE module is still in connected mode No LTE module or LTE module fails RidgeWave 6900 User Manual... -
Page 13: Mounting Kit Installation
Product Overview Mounting Kit Installation Attach the Articulation Pole to the Enclosure Attach the articulation pole to the back of the RidgeWave 6900 using M6*16 screws and washers. A -45 or +45 degree adjustment Dual-Polarized Antenna Cross-Polarized Antenna Wall or Pole Mounting 2.1 Mounting on Wall... - Page 14 Fix the T-formed Bracket to the pole by using the stainless hose clamp. Mounting the RidgeWave 6900 to the T-formed Bracket Attach the articulation pole (the RidgeWave 6900 enclosure) to the T-formed bracket by using M8x40 bolts, nut, spring washer and washer.
- Page 15 Find the location and best angle for getting the strongest signal from the base station. The RidgeWave 6900 must be directed towards the nearest base station. Adjusting the router position to get a better reception and/or fine-tuning the router orientation (in...
- Page 16 Product Overview Grounding the CPE to Complete the Installation Attach the grounding wire to the CPE and tighten the screw RidgeWave 6900 User Manual...
-
Page 17: Router Installation Instructions
IEEE 802.1at compliant, Power+Data (P+D)/OUT port. Connect another Ethernet cable (RJ-45) directly to the Data/IN port and the other end of cable to a switch or broadband router. Plug the PoE power cable to an electrical outlet to power on your RidgeWave 6900. RidgeWave 6900 User Manual... - Page 18 Product Overview 2. Set up your 4G/LTE Internet Connection Step 1: Unscrew the cap of SIM card slot. RidgeWave 6900 User Manual...
- Page 19 It is recommended to use an industrial-grade SIM card. Attention Step 3: Screw the cap back tightly. Please power off your RidgeWave 6900 before inserting or removing the SIM card. Warning RidgeWave 6900 User Manual...
-
Page 20: Chapter 3: Basic Installation
If not, please refer to your Windows-related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the RidgeWave 6900. To configure other types of workstations, please consult the manufacturer’s documentation. RidgeWave 6900 User Manual... -
Page 21: Network Configuration - Ipv4
Network and Sharing Center When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave 6900 User Manual... - Page 22 In the TCP/IPv4 properties window, select the Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave 6900 User Manual...
-
Page 23: Configuring Pc In Windows 7/8 (Ipv4)
Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave 6900 User Manual... - Page 24 In the TCP/IPv4 properties window, select the Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave 6900 User Manual...
-
Page 25: Configuring Pc In Windows Vista (Ipv4)
Center at the top bar. When the Network and Sharing Center window pops up, select and click on Manage network connections on the left window pane. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave 6900 User Manual... - Page 26 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave 6900 User Manual...
-
Page 27: Network Configuration - Ipv6
Network and Sharing Center When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave 6900 User Manual... - Page 28 In the TCP/IPv6 properties window, select the Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave 6900 User Manual...
-
Page 29: Configuring Pc In Windows 7/8 (Ipv6)
Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave 6900 User Manual... - Page 30 In the TCP/IPv6 properties window, select the Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave 6900 User Manual...
-
Page 31: Configuring Pc In Windows Vista (Ipv6)
Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections on the left window pane. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave 6900 User Manual... - Page 32 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave 6900 User Manual...
-
Page 33: Default Settings
Attention release it, to be sure you power cycle the device again. Device LAN IP Settings IP Address: 192.168.0.1 Subnet Mask: 255.255.255.0 DHCP Server: DHCP server is enabled. Start IP Address: 192.168.0.50 IP pool counts: 150 RidgeWave 6900 User Manual... -
Page 34: Chapter 4: Device Configuration
“Go”, a user name and password window prompt appears. The default username is “admin” and the password is located on the back of the device for the Administrator. Congratulations! You have successfully logged on to your RidgeWave 6900 RidgeWave 6900 User Manual... - Page 35 Device Configuration Login to your Device Once you have logged on to your RidgeWave 6900 via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you...
-
Page 36: Status
Model Name: Name of the router for identification purpose. Firmware Version: Software version currently loaded in the router MAC Address: A unique number that identifies the router Data-Time: Setup correct time on the RidgeWave 6900 with your PC. Check on Time Zone section for more configuration information. -
Page 37: System Status
% rate may result in slow Internet loading, experiencing video lags, etc. To reduce high CPU consumption by resetting the device, power off and on, an easiest way to regain the service. Memory Total / Free / Cached (in Kbyte): Display the memory consumptions in kilobytes (kB). RidgeWave 6900 User Manual... -
Page 38: System Log
Device Configuration Status System Log In system log, you can check the operations status and any glitches to the router. Refresh: Press this button to refresh the statistics. RidgeWave 6900 User Manual... -
Page 39: 3G/4G-Lte Status
Card IMEI: The unique identification number that is used to identify the 3G/4G-LTE module. Card IMSI: The international mobile subscriber identity used to uniquely identify the 3G/4G-LTE module. Network Mode / Band: Show the using network mode and LTE band. Usage Allowance RidgeWave 6900 User Manual... -
Page 40: Statistics
Transmit Total Bytes: This field displays the total number of bytes transmitted until the latest second since system is up. Receive Frames of Current Connection: This field displays the number of frames received until the latest second for the current connection. RidgeWave 6900 User Manual... - Page 41 Receive Total Frames: This field displays the total number of frames received until the latest second since system is up. Receive Total Bytes: This field displays the total frames received till the latest second since system is up. Refresh: Press this button to refresh the statistics. RidgeWave 6900 User Manual...
- Page 42 Receive CRC Errors: This field displays the number of error packets on this port. Receive Under-size Frames: This field displays the number of under-size frames received until the latest second. Refresh: Press this button to refresh the statistics. RidgeWave 6900 User Manual...
-
Page 43: Dhcp Table
MAC Address: The MAC address of a device, e.g. PC, notebook, printer, etc., that is corresponded with the IP address. VRRP Status Current Status: Display current VRRP status, Master or Backup. Current Master: Display the IP address of the Master RidgeWave 6900 User Manual... -
Page 44: Quick Start
Step 2 – Time Zone Choose your time zone. Click NEXT to continue. Step 3 – ISP Connection Type Set up your Internet connection. 3.1 Select an appropriate WAN connection protocol then click NEXT to continue. RidgeWave 6900 User Manual... - Page 45 The Setup Wizard has completed. Click on BACK to make changes or correct mistakes. Click NEXT to save the current settings and complete the Quick Start setups. Go back to the Status > Device Info to view the status. RidgeWave 6900 User Manual...
-
Page 46: Configuration
Click to access and configure the available features in the following: Interface Setup, Advanced Setup, Access Management, and Maintenance. These functions are described in the following sections. Interface Setup Here are the features under Interface Setup: Internet, LAN and Loopback. Internet ❖ 3G/4G-LTE RidgeWave 6900 User Manual... - Page 47 (ROM) in every hour. Once the feature is turned on, you can see the amount of data used and how many days left before next billing cycle starts. Go to Status >> 3G/4G-LTE Status page for details. RidgeWave 6900 User Manual...
- Page 48 WAN IP address; features such as routing capabilities, NAT, firewall, etc., are being disabled. The client router that is behind the RidgeWave 6900 now obtains a WAN IP address. When disabled, RidgeWave 6900 is in router mode that it handles a WAN IP address and all features become available.
- Page 49 MTU: Maximum Transmission Unit. The size of the largest datagram (excluding media-specific headers) an IP attempts to send through the interface. 0 means to use default MTU size, 1500byte. Click Save to apply settings. RidgeWave 6900 User Manual...
-
Page 50: Lan
IPv4 Parameters IP Address: Enter the IP address of Router in dotted decimal notation, for example, 192.168.0.1 (factory default). IP Subnet Mask: The default is 255.255.255.0. User can change it to other such as 255.255.255.128. RidgeWave 6900 User Manual... - Page 51 If set to Disabled, the DHCP server will be disabled. If set to Relay, the RidgeWave 6900 acts as a surrogate DHCP server and relays DHCP requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.
- Page 52 (prefix) advertised by routers. Routers advertise prefixes that identify the subnet(s) associated with a link, while hosts generate an "interface identifier" that uniquely identifies an interface on a subnet. An address is formed by combining the two. When using stateless configuration, you needn’t configure RidgeWave 6900 User Manual...
- Page 53 Router Advertisement messages periodically which would multicast the IPv6 Prefix information (similar to v4 network number 192.168.0.0) to all LAN devices if the field is enabled. We suggest enabling this field. Click Save to apply settings. RidgeWave 6900 User Manual...
-
Page 54: Loopback
Telnet management IP and involved in BGP as BGP Update-Source and OSPF as Router ID. IP Address: Enter a dedicated IP address for the loopback interface. IP Subnet Mask: Enter the subnet mask for the loopback interface. Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 55: Advanced Setup
SPI: If you enabled SPI, all traffics initiated from WAN would be blocked, including DMZ, Virtual Server, and ACL WAN side. Enabled: It activates your SPI function. Disabled: It disables the SPI function. Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 56: Routing
Gateway IP Address/Interface: This is the gateway IP address or existing interface to which packets are to be forwarded. Metric: It represents the cost of transmission for routing purposes. The number need not be precise, but it must be between 1 and 15. Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 57: Dynamic Routing
The backbone must be contiguous, i.e. there must be no disconnected segments. However, area border routers do not need to be physically connected to the backbone - connection to it may be simulated using a virtual link. RidgeWave 6900 User Manual... - Page 58 AS number are the same, thus, an inter-AS communication, please enable the allowas-in. Otherwise, the router only support EBGP routing between different domains. Next-Hop-Self: Enable to use the router’s own loopback address as the next-hop address. RidgeWave 6900 User Manual...
-
Page 59: Nat
Service Index: Associated to EWAN interface marking each EWAN service (0-7), to select which EWAN service the DMZ and Virtual server are applied to. Click DMZ or Virtual Server to move on to set the DMZ or Virtual Server parameters, which are represented in the following scenario. RidgeWave 6900 User Manual... - Page 60 Example: Skip port 80 (UDP/TCP) in the list. All Incoming request to access to port 80 (Web GUI) will be forwarded to the embedded HTTP server of RidgeWave 6900 instead of the DMZ host. Click Add to add an entry to the Except Listing.
- Page 61 Device Configuration Advanced Setup Virtual Server is also known as Port Forwarding that allows RidgeWave 6900 to direct incoming traffic to a specific device in the network. Configure a virtual rule in RidgeWave 6900 for remote users accessing services such as Web or FTP services via the public (WAN) IP address that can be automatically redirected to local servers in the LAN network.
- Page 62 SMTP (Simple Mail Transfer Protocol) TCP & UDP DNS (Domain Name Server) TFTP (Trivial File Transfer Protocol) World Wide Web HTTP POP3 (Post Office Protocol Version 3) TCP & UDP HTTPS 1503 T.120 1720 H.323 7070 RealAudio RidgeWave 6900 User Manual...
- Page 63 Step 2: Login to the Gateway and go to Configuration / Advanced Setup / NAT / Virtual Server. FTP server uses TCP protocol with port 21. Enter “21” to Start and End Port Number. The RidgeWave 6900 will accept port 21 requests from WAN side.
-
Page 64: Vrrp
When deactivated, the lower priority backup is left in the master state. VRIP: An IP address which is associated with the virtual router. Advertisement period: Indicates the time interval in seconds between advertisements. Default in 1 second. RidgeWave 6900 User Manual... -
Page 65: Static Dns
192.0.32.10 (IPv4). IP Address: The IP address you are going to give a specific domain name. Domain Name: The friendly domain name for the IP address. Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 66: Time Schedule
End Time: The ending point of the interval for the timeslot, anytime in 00:00 – 24:00. Click Save to apply your settings. Example, you can add a timeslot named “TimeSlot1” which features a period from 9:00 of Monday to 18:00 of Tuesday. Another TimeSlot2 spanning from 09:00 to 18:00 of Wednesday RidgeWave 6900 User Manual... -
Page 67: Mail Alert
WAN IP change has been detected. Recipient’s Email (3G/4G-LTE Usage Allowance): Enter a valid e-mail address to receive an alert message when the 3G or 4G/LTE over Usage Allowance occurs. Click Apply button to save settings RidgeWave 6900 User Manual... -
Page 68: Access Management
When accessing to the web server (Web GUI), the browser will issue a warning page. To import certificates, go to Maintenance >> Certificate Management to upload files. Otherwise, select Default certificate and CA. Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 69: Snmp
SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. The RidgeWave 6900 serves as a SNMP agent that allows a manager station to manage and monitor the router through the network. SNMP: Activate to enable SNMP. - Page 70 Device Configuration Access Management Privacy Protocol: Select the privacy mode, DES and AES. Privacy Key: Set the privacy key, 8-31 characters. Click Save to apply settings. RidgeWave 6900 User Manual...
-
Page 71: Syslog
Remote System Log: Select Activated to enable this feature Server IP Address: Assign the remote log server IP address. Server UDP Port: Assign the remote log server port, 514 is commonly used. Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 72: Universal Plug & Play
UPnP: Select this checkbox to activate UPnP. Be aware that anyone could use an UPnP application to open the web configuration’s login screen without entering the RidgeWave 6900's IP address Auto-configured: Select this check box to allow UPnP-enabled applications to automatically... -
Page 73: Dynamic Dns (Ddns)
Username / Password: Enter the user name and password of the account you created with this service provider. Wildcard support: Select this check box to enable DYNDNS Wildcard. Period: Set the time period on how often the RidgeWave 6900 will update the DDNS server with your current external IP address. Click Save to apply settings. - Page 74 Example: How to register a DDNS account If you do not have an account with Dynamic DNS, please go to www.dyndns.org to register an account first. User test1 register a Dynamic Domain Names in DDNS provider http://www.dyndns.org/ DDNS: www.hometest.com using username/password test/test RidgeWave 6900 User Manual...
-
Page 75: Access Control
Active: Yes to activate the rule. Secure IP Address: The default 0.0.0.0 allows any client to use this service to manage the RidgeWave 6900. Type an IP address range to restrict access to the client(s) without a matching IP address. - Page 76 Device Configuration Access Management Default Rule 2: (Index 2), an ACL rule to open Ping to WAN side. RidgeWave 6900 User Manual...
-
Page 77: Packet Filter
Type: Choose type of field you want to specify to monitor. Select “IPv4” for IPv4 address, port number and protocol. Select “IPv6” for IPv6 address, port number and protocol. Select “MAC” for MAC address. RidgeWave 6900 User Manual... - Page 78 Source Port Number: The source port number of packets to be monitored. Destination IP (IPv6) Address/ Prefix: The destination subnet IP address. Destination Port Number: This is the Port or Port Ranges that defines the application. DSCP: show the set DSCP. RidgeWave 6900 User Manual...
- Page 79 Protocol: It is the packet protocol type used by the application. Select either TCP or UDP or ICMP or ICMPv6 MAC Source MAC Address: show the MAC address of the rule applied. Click Save to apply settings. RidgeWave 6900 User Manual...
- Page 80 In a word, the command serves as a switch to the access of some specific URL with the filter on. URL (Host): Specified URL which is prohibited from accessing. Click Save to apply settings. RidgeWave 6900 User Manual...
-
Page 81: Parental Control
Parent Control: Enable the feature by clicking the Activated Host Name: It is the domain name of your OpenDNS. If you don’t have one, please leave it blink. Username / Password: Put down your OpenDNS account username and password Click Save to apply settings. RidgeWave 6900 User Manual... -
Page 82: Maintenance
The User account is with limited access (specified by advanced users with admin account) to the GUI. Total of 8 accounts can be created to grant access to manage the RidgeWave 6900 via the web page. - Page 83 Interface Setup / Advanced Setup / Access Management / Maintenance: Enable to grant this user access to these features. When someone accesses to the RidgeWave 6900 using this “user” account, he/she can only manage and configure the features that is pre-selected in Web GUI Permission for this account.
-
Page 84: Time Zone
With default, RidgeWave 6900 does not contain the correct local time and date. There are several options to setup, maintain, and configure current local time/date on the RidgeWave 6900. If you plan to use Time Schedule feature, it is extremely important you set up the Time Zone correctly. -
Page 85: Firmware & Configuration
. To upgrade the firmware of the RidgeWave 6900, you should download or copy the firmware to your local environment first. Click “Choose File” to specify the path of the firmware file. Then, click “Upgrade”... -
Page 86: System Restart
You may also restore your router to factory settings by holding the small Reset pinhole button on the back of your router in about more than 6s seconds whilst the router is turned on. RidgeWave 6900 User Manual... -
Page 87: Auto Reboot
Device Configuration Maintenance Auto Reboot Schedule an automatic reboot for your RidgeWave 6900 to ensure proper operation and best performance. This reboot will only reboot with current configuration settings and not overwrite any existing settings. Click Save to apply settings Example: Schedule RidgeWave 6900 to reboot at 10:00pm (22:00) every weekday (Monday thru Friday) and reboot at 9:00am on Saturday and Sunday. -
Page 88: Diagnostics Tool
Click Yes, enter the IP address or domain then Start Trace Route. IP Address or Domain: Set the destination host (IP, domain name) to be traced. Max TTL value: Set the max Time to live (TTL) value. Shown as we “trace” www.billion.com below. RidgeWave 6900 User Manual... - Page 89 Device Configuration Maintenance Ping other IP Address: Click Yes to ping any desired IP address or a domain. Click START to begin to diagnose the connection. RidgeWave 6900 User Manual...
-
Page 90: Chapter 5: Troubleshooting
Troubleshooting Chapter 5: Troubleshooting If your RidgeWave 6900 is not functioning properly, you can refer to this chapter for simple troubleshooting before contacting your service provider support. This can save you time and effort but if symptoms persist, consult your service provider. -
Page 91: Recovery Procedures
Please note that the router will only respond with its web interface at this address (192.168.1.1), and will not respond to ping request from your PC or other telnet operations. RidgeWave 6900 User Manual... -
Page 92: Appendix: Product Support & Contact
If you come across any problems please contact the dealer from where you have purchased the product. Contact BEC @ http://www.bectechnologies.net MAC OS is a registered Trademark of Apple Computer, Inc. Windows 7/98, Windows NT, Windows 2000, Windows ME, Windows XP, and Windows Vista are registered Trademarks of Microsoft Corporation. RidgeWave 6900 User Manual... - Page 93 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. V1041146 RidgeWave 6900 User Manual...
