Summary of Contents for BEC 5102 Series

  • Page 1 5102 Series (802.11g) ADSL2+ Modem/Router User’s Manual...
  • Page 2: Table Of Contents

    1.2 Features of the 5102 Series ..........3 1.3 Applications for the 5102 Series ..........6 Chapter 2 ....................7 2.1 Important note for using the 5102 Series ADSL Router..7 2.2 Package Contents ..............7 2.3 The Front LEDs ..............8 2.4 The Rear Ports ..............
  • Page 3: Chapter 1

    Introduction the 5102 Series 1.1 Introducing the 5102 Series Welcome to the BEC 5102 Series ADSL2+ Router. Your BEC router is an “all-in-one” unit, combining an ADSL modem, ADSL router and Ethernet network switch, providing everything you need to get the machines on your network connected to the Internet over your ADSL broadband connection.
  • Page 4 to target a machine on your network. Secondly, it can block and redirect certain ports to limit the services that outside users can access. For example, to ensure that games and other Internet applications will run properly, user can open some specific ports for outside users to access internal services in network.
  • Page 5: Features Of The 5102 Series

    1.2 Features of the 5102 Series ADSL Multi-Mode Standard supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It also supports rate management that allows ADSL subscribers to select an Internet access speed suiting their needs and budgets. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2;...
  • Page 6 (ALG) are supported such as web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping, NetMeeting, IP phone and others. Firewall Supports simple firewall with NAT technology and provides option for blocking access from Internet, like Telnet, FTP, TFTP, WEB, SNMP and IGMP. Domain Name System (DNS) relay Provides an easy way to map the domain name (a friendly name for users such as www.yahoo.com) and IP address.
  • Page 7 client IP addresses and distribute them including IP address, subnet mask as well as DNS IP address to local computers. It provides an easy way to manage the local IP network. RIP1/2 Routing Supports RIP1/2 routing protocol for routing capability. Simple Network Management Protocol (SNMP) It is an easy way to remotely manage the router via SNMP.
  • Page 8: Applications For The 5102 Series

    1.3 Applications for the 5102 Series...
  • Page 9: Chapter 2

    Do not use the same power source for the 5102 Series as other equipment. Do not open or repair the case yourself. If the 5102 Series is Warning too hot, turn off the power immediately and have it repaired at a qualified service center.
  • Page 10: The Front Leds

    2.3 The Front LEDs 5102 5102S 5102G Meaning PPP : Lit steady when there is a PPPoA / PPPoE connection. Lit when successfully connected to an ADSL DSLAM ADSL: (“linesync”). Lit when connected to an Ethernet device. LAN Port Green for 100Mbps; Orange for 10Mbps. 1-4: Blinking when data is Transmitted / Received.
  • Page 11: The Rear Ports

    2.4 The Rear Ports 5102 5102S 5102G Port Meaning Connect the supplied power adapter to this jack. After the device is powered on, press it to reset the device or restore to factory default settings. RESET 0-3 seconds: reset the device 6 seconds above: restore to factory default settings (this is used when you can not login to the router, e.g.
  • Page 12: Cabling

    LAN Link and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables. Ensure that all other devices connected to the same telephone line as your BEC router (e.g. telephones, fax machines, analogue modems) have a line filter connected between them...
  • Page 13: Chapter 3

    If not, please refer to your Windows-related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the 5102 Series. To configure other types of workstations, please consult the manufacturer’s documentation.
  • Page 14 Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 15 Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 16 Configuring PC in Windows 98/Me 1.Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2.Select TCP/IP ->NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.Select the Obtain an IP address automatically radio button.
  • Page 17 Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2.Select TCP/IP Protocol and click Properties. 3.Select the Obtain an IP address from a DHCP server radio button and click OK.
  • Page 18: Factory Default Settings

    3.2 Factory Default Settings Before configuring your, you need to know the following default settings. Web Interface: Username: admin Password: admin LAN Device IP Settings: IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 ISP setting in WAN site: PPPoE DHCP server: DHCP server is enabled. Start IP Address: 192.168.1.100 IP pool counts: 100 3.2.1 Username and Password...
  • Page 19: Lan And Wan Port Addresses

    3.3 LAN and WAN Port Addresses The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown below. LAN Port WAN Port IP address 192.168.1.254 The PPPoE function is enabled to Subnet Mask 255.255.255.0 automatically get the WAN port DHCP server function...
  • Page 20: Configuring With Your Web Browser

    Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a user name and password window prompt will appear. The default username and password are “admin” and “admin”. Congratulation! You are now successfully logon to the 5102 Series ADSL Router!
  • Page 21: Chapter 4

    Interface Setup (Internet, LAN, Wireless) Advanced Setup (Routing, NAT, ADSL) Access Management (ACL, IP Filter, SNMP, UPnP, DDNS) Maintenance (Administration, Time Zone, Firmware, SysRestart, Diagnositics) Status Please see the relevant sections of this manual for detailed instructions on how to configure your BEC router.
  • Page 22: Quick Start

    4.1 Quick Start For detailed instructions on configuring WAN settings, see the Interface Setup section of this manual. The information you need for the Quick Start to get you online are your login (often in the form of username@ispname), your password, and the encapsulation type. The following is the Quick Start step, please follow according to the instruction step by step.
  • Page 23 Step1. Set your new password. Step2: Choose your time zone...
  • Page 24 Step3: Set your Internet connection...
  • Page 25 Step4: Restart your ADSL Router...
  • Page 26: Interface Setup

    4.2 Interface Setup Click this item to access the following sub-items that configure the ADSL router: Internet, LAN, and Wireless These functions are described in the following sections. 4.2.1 Internet...
  • Page 27 ATM VC Virtual Circuit: VPI (Virtual Path Identifier) and VCI (Virtual Channel Identifier) define a virtual circuit. VPI: The valid range for the VPI is 0 to 255. Enter the VPI assigned to you. This field may already be configured. VCI: The valid range for the VCI is 32 to 65535.
  • Page 28 Multicast: IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish membership in a Multicast group - it is not used to carry user data. The 5102 Series supports both IGMP version 1 (IGMP-v1) and IGMP-v2. Select None to disable it...
  • Page 29 Multicast: IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish membership in a Multicast group - it is not used to carry user data. The 5102 Series supports both IGMP version 1 (IGMP-v1) and IGMP-v2. Select None to disable it...
  • Page 30 TCP/IP configuration at start-up from a server. DHCP: If set to Enable, your 5102 Series can assign IP addresses, an IP default gateway and DNS servers to Windows 95, Windows NT and other systems that support the DHCP client.
  • Page 31 4.2.3 Wireless 802.11g is only supported for the 5102G This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as simple as two computers with wireless LAN cards communicating in a peer-to-peer network or as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to the wired LAN.
  • Page 32 Wireless LAN Access Point: Default setting is set to Activated. If you do not have any wireless, both 802.11g and 802.11b, device in your network, select Deactived. SSID: The SSID is the unique name of a wireless access point (AP) to be distinguished from another.
  • Page 33 both 11g and 11b devices in your network, then keep the default in mixed mode. From the drop-down manual, you can select 802.11g if you have only 11g card. If you have only 11b card, then select 802.11b. Wireless MAC Address Filter The MAC filter screen allows you to configure the router to give exclusive access to up to 32 devices (Allow Association) or exclude up to 32 devices from accessing the router (Deny Association).
  • Page 34 ("0-9", "A-F"). You must configure all four keys, but only one key can be activated at any one time. The default key is key 1. WPA-PSK Encryption: TKIP (Temporal Key Integrity Protocol) utilizes a stronger encryption method and incorporates Message Integrity Code (MIC) to provide protection against hackers.
  • Page 35: Advanced Setup

    4.3 Advanced Setup 4.3.1 Routing If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet. #: Item number Dest IP: IP address of the destination network Mask: The destination mask address.
  • Page 36 ADD Route Destination IP Address:This is the destination subnet IP address. IP Subnet Mask:It is the destination IP addresses based on above destination subnet IP Gateway IP Address:This is the gateway IP address to which packets are to be forwarded. Metric:It represents the cost of transmission for routing purposes.
  • Page 37 4.3.2 NAT The NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet. The default setting is Dynamic NAPT. It provides dynamic Network Address Translation capability between LAN and multiple WAN connections, and the LAN traffic is routed to appropriate WAN connections based on the destination IP addresses and Route Table.
  • Page 38 The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets will be checked by the Firewall and NAT algorithms then passed to the DMZ host, when a packet received does not use a port number used by any other Virtual Server entries.
  • Page 39 Virtual Server In TCP/IP and UDP networks a port is a 16-bit number used to identify which application program (usually a server) incoming connections should be delivered to. Some ports have numbers that are pre-assigned to them by the IANA (the Internet Assigned Numbers Authority), and these are referred to as “well-known ports”.
  • Page 40 Rule Index: Choose the rule number. Start Port Number: Enter a port number in this field. End Port Number: Enter a port number in this field. Local IP Address: Enter your server IP address in this field.
  • Page 41 IP Address Mapping Rule Index: Choose the rule number. Rule Type: One-to-one: This is the mode maps one local IP address to one global IP address. Note that port numbers do not change for the One-to-one NAT mapping type. Many-to-One: This is the mode maps multiple local IP addresses to one global IP address. This is equivalent to Many to One (i.e., PAT, port address translation).
  • Page 42 have a dynamic IP address from your ISP. Public End IP: This is the ending Inside Public IP Address. This field is N/A for One-to-one, Many-to-One and Server mapping types. Using port forwarding does have security implications, as outside users will be able to connect to PCs on your network.
  • Page 43 4.3.3 ADSL ADSL Mode: The default setting is Auto Sync-UP. This mode will automatically detect your ADSL, ADSL2+, ADSL2, G.dmt, G.lite, and T1.413. But in some area, multimode cannot detect the ADSL line code well. If it is the case, please adjust the ADSL line code to G.dmt or T1.413 first.
  • Page 44: Access Management

    ACL Rule Index: This is item number Secure IP Address: The default 0.0.0.0 allows any client to use this service to remotely manage the 5102 Series. Type an IP address to restrict access to a client with a matching IP address.
  • Page 45 4.4.2 IP Filter You may use telnet or Web to remotely manage the ADSL Router. User just needs to enable Telnet or Web and give it an IP address that want to access the ADSL Router. The default IP 0.0.0.0 allows any client to use this service to remotely manage the ADSL Router. IP Filter Set Editing IP filter Set Index: This is item number Interface: Select which channel (PVC) to configure.
  • Page 46 Source IP Address: The source IP address or range of packets to be monitored. Subnet Mask: It is the destination IP addresses based on above destination subnet IP Source Port Number: This Port or Port Ranges defines the port allowed to be used by the Remote/WAN to connect to the application.
  • Page 47 Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. 5102 series supports SNMP agent functionality which allows a manager station to manage and monitor the router through the network.
  • Page 48 Windows XP in order to support UPnP. Windows 2000 does not support UPnP. UPnP: Select this checkbox to activate UPnP. Be aware that anyone could use a UPnP application to open the web configurator's login screen without entering the 5102 Series 's IP address...
  • Page 49 Dynamic DNS: Select this check box to use dynamic DNS. Service Provider: Select the name of your Dynamic DNS service provider. My Host Name: Type the domain name assigned to your 5102 Series by your Dynamic DNS provider. E-mail Address: Type your e-mail address.
  • Page 50: Maintenance

    4.5 Maintenance 4.5.1 Administrator In factory setting, the default password is admin, and that for user is also password. You can change the default password to ensure that someone cannot adjust your settings without your permission. Every time you change your password, please record the password and keep it at a safe place.
  • Page 51 4.5.2 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network. Choose your local time zone. After a successful connection to the Internet, the router will retrieve the correct local time from the SNTP server you have specified.
  • Page 52 To upgrade the firmware of 5102 Series, you should download or copy the firmware to your local environment first. Press the “Browse…” button to specify the path of the firmware file.
  • Page 53 DO NOT power down the router or interrupt the firmware upgrading while it is still in process. Improper operation could damage the router. Warning...
  • Page 54 4.5.4 SysRestart Click SysRestart with option Current Settings to reboot your router (and restore your last saved configuration). If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.
  • Page 55 4.5.6 Diagnostics The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides...
  • Page 56: Status

    4.6 Status 4.6.1 Device Info Device Information Firmware version: This is the Firmware version MAC Address: This is the MAC Address IP Address: LAN port IP address. Sub Net Mask: LAN port IP subnet mask. DHCP Server: LAN port DHCP role - Enabled, Relay or disabled Status: “Not connected”...
  • Page 57 Virtual Circuit: There are eight groups of PVC can be defined. VPI: The valid range for the VPI is 0 to 255 VCI: The valid range for the VCI is 32 to 65535 Connection Type: Name of the WAN connection. VPI/VCI: Virtual Path Identifier and Virtual Channel Identifier IP Address: WAN port IP address.
  • Page 58 4.6.2 System Log Display system logs accumulated up to the present time. You can trace historical information with this function.
  • Page 59 4.6.3 Statistics Read-only information here includes port status and packet specific statistics. Also provided are "Transmit Statistics" and "Receive Statistics". Ethernet Interface: This field displays the type of port Transmit Frames: This field displays the number of frames transmitted in the last second.
  • Page 60 ADSL Transmit total PDUs: This field displays the number of total PDU transmitted in the last second. Transmit total Error Counts: This field displays the number of total error transmitted in the last second. Receive total PDUs: This field displays the number of total PDU received in the last second.
  • Page 61: Chapter 5

    Chapter 5 Troubleshooting If the ADSL2+ Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider. This could save your time and effort but if the symptoms persist, then consult your service provider. Problems starting up the router Problem Corrective Action...
  • Page 62: Problems With The Lan Interface

    Frequent loss of Ensure that all other devices connected to the same ADSL linesync telephone line as your router (e.g. telephones, fax machines, (disconnections). analogue modems) have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure that all line filters are correctly installed and the right way around.
  • Page 63: Appendix

    APPENDIX Product Support and Contact Information Most problems can be solved by referring to the Troubleshooting section in the User’s Manual. If you cannot resolve the problem with the Troubleshooting chapter, please contact your Internet Service Provider, ISP.
