Summary of Contents for BEC 6500AEL
- Page 1 BEC 6500AEL 4G/LTE Enterprise Multi-Service Router Quick Start Guide...
- Page 3 ✓ DC Power Adapter 15V DC 1.6A x 1 ✓ 4G/LTE Antenna x 2 ( 6500AEL R18/R21 is using four (4) 4G/LTE antennas) NOTE: ALL IMAGES SHOWN ARE FOR ILLUSTRATION PURPOSE ONLY. PACKAGE CONTENTS MAY DIFFER FROM ACTUAL PRODUCTS. ⚫...
- Page 4 PORT MEANING Screw the supplied mobile LTE antennas onto the antenna connectors on both LTE Antenna sides. Connectors (6500AEL R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas) STATUS DESCRIPTION Green System is up and ready Power Boot failure...
-
Page 5: Rear Panel - Ports / Connectors
Antenna Screw the supplied Wi-Fi antennas onto the antenna connectors on both sides Connectors (6500AEL R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas) LTE Antenna Connectors Screw the supplied mobile LTE antennas onto the antenna connectors on both sides... -
Page 6: Hardware Connection
Quick Start Guide Hardware Connection Back Panel Ports & Connectors Wi-Fi & LTE Antenna Connectors (Standard Version) -
Page 7: Hardware Installation
BEC 6500AEL 4G/LTE Enterprise Multi-Service Router Wi-Fi & LTE Antenna Connectors (6500AEL R18 / R21 Only) Hardware Installation Power Connection Plug in the supplied power adapter to the wall jack, the other side to device then power ON the 6500AEL by pressing the Power On/Off button. - Page 8 Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other side to the PC’s Ethernet interface. 3. WAN Link Interface and Connection BEC 6500AEL supports failover and failback on multiple WAN interfaces, 4G/LTE and Ethernet WAN <Please refer to User Manual for detailed Internet setup> 3.1 4G_LTE Connection Slide the SIM card into the card slot of the device with the gold contact facing down.
- Page 9 Cable Modem, VDSL, Fiber Modem or PON optic lines. 4. USB for Network File Sharing BEC 6500AEL has built-in FTP and Samba Servers, simply plug in an external USB HD then follow the instruction setup in the User Guide.
-
Page 10: Connecting To The Router
Quick Setup Your Router Use the Quick Start for fast connection setup. Wired Broadband Connection - Before start configuring the 6500AEL, make sure you have the Ethernet WAN connected with your Internet box or fiber line. Step 1: Change administration password Setup a new password for “admin”... - Page 11 BEC 6500AEL 4G/LTE Enterprise Multi-Service Router Step 3: Setup Wireless Connection Access Point: select Activated SSID: Assign a unique name Channel: pick from 1~11 Security Type: select a mode - Disable (No security) - WPA - WPA2 (Most secure one)
-
Page 12: Troubleshooting
Quick Start Guide Troubleshooting 1. None of the LEDs are on when you turn on the router. Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. In this case you should contact technical support. 2.
