User Manual
BEC 4700A/AZ
(4G/LTE) Wireless Outdoor Router
Last revised: July 2020
Version release: v2.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4700A and is the answer not in the manual?

Questions and answers

Related Manuals for BEC 4700A

Summary of Contents for BEC 4700A

  • Page 1 User Manual BEC 4700A/AZ (4G/LTE) Wireless Outdoor Router Last revised: July 2020 Version release: v2.1...
  • Page 2 Copyright Notice Copyright@ 2020 BEC Technologies Inc. All rights reserved. BEC Technologies reserves the right to change and make improvement to this manual at any time without prior notice. No part of this document may be reproduced, copied, transmitted in any form or by any means without prior written permission from BEC Technologies, Inc.

  • Page 3: Table Of Contents

    MPORTANT OTE FOR SING OUTER ................8 ACKAGE ONTENTS ................9 EVICE ESCRIPTION Hardware Overiew (BEC 4700AZ) ..............9 Hardware Overiew (BEC 4700A) ..............11 ........................11 ..............13 OUNTING NSTALLATION ............19 OUTER NSTALLATION NSTRUCTIONS ............. 23 YSTEM ECOVERY ROCEDURES CHAPTER 3: BASIC INSTALLATION ....
  • Page 4 ................37 EFAULT ETTINGS ISP ............... 38 NFORMATION FROM CHAPTER 4: DEVICE CONFIGURATION ..39 ................. 39 OGIN TO YOUR EVICE ....................42 TATUS Device Info ...................... 42 System Status ....................44 System Log ...................... 44 4G/LTE Status ....................45 Wireless Status ....................
  • Page 5 General Setting ......................99 Built-in User Account ....................102 Authorized of Client ....................103 Walled Garden ......................104 Advertisement ......................105 Hotspot Status Log ..................... 106 Customization ......................107 Advanced Setup .................... 109 Firewall ........................109 Static Routing ......................110 Dynamic Routing ......................
  • Page 6 Time Zone ........................199 License ........................200 Firmware & Configuration ..................201 System Restart ......................202 Auto Reboot ........................ 203 Diagnostics Tool ......................204 CHAPTER 5: TROUBLESHOOTING .... 206 Problems with the Router ................206 Problem with LAN Interface ................206 Recovery Procedures ..................

  • Page 7: Copyright Notice

    With the next wireless generation, 802.11ac, integrated in the BEC 4700 A/AZ, the router delivers fast Wi-Fi speeds of up to 2000Mbps. The BEC 4700 A/AZ supports a link rate up to 300Mbps in 2.4GHz frequency range & 1700Mbps in 5GHz range and is also backward compatible with existing 802.11 a / b / g / n wireless equipment in the network.
  • Page 8 Support a WEB GUI page to install this device quickly. With this wizard, simple steps will get you connected to the Internet immediately. Firmware Upgradeable Device can be upgraded to the latest firmware through the WEB based GUI. BEC 4700A / 4700AZ User Manual...

  • Page 9: Features & Specifications

    • Universal Plug and Play (UPnP) Compliant • Dynamic Domain Name System (DDNS) • Virtual Server and DMZ • SNTP, DNS proxy • IGMP snooping and IGMP proxy • MLD snooping and MLD proxy BEC 4700A / 4700AZ User Manual...
  • Page 10 • AP, Client Bridge and WDS Operational Modes • Multiple SSID (4 SSIDs), BSSID • Wireless MAC filtering • Wireless Client Isolation • Support up to 32 Connected Clients • Wi-Fi client rate-limiting Management • Quick Installation wizard BEC 4700A / 4700AZ User Manual...
  • Page 11 • Firmware upgrades and configuration data upload and download via web-based GUI • Supports DHCP server / client / relay • Supports SNMP v1, v2, v3, MIB-I and MIB-II • TR-069 supports remote management BEC 4700A / 4700AZ User Manual...

  • Page 12: Hardware Specifications

    • Reset Button • LED Indicators: (4700AZ) Power/Boot, LAN(PoE), EWAN, WI-FI(2.4GHz & 5GHz), LTE RSSI, and Internet (4700A) Power/Boot, LAN(PoE), WAN, Wi-Fi Internet Physical Specifications • Dimensions (W*H*D): 8.5" x 7.5" x 3"(257mm x 227mm x 91mm) • Weight: 2kgs (4.4lbs) (Without Mount) •...

  • Page 13: Application Diagram

    Introduction Application Diagram Application Diagram 4700AZ BEC 4700A / 4700AZ User Manual...

  • Page 14: Chapter 2: Product Overview

    Package Contents ✓ The BEC 4700A / AZ (4G/LTE) Wireless Outdoor Router x 1 ✓ M25 Cable Gland x 2 ✓ Quick Start Guide x 1 ✓...

  • Page 15: Device Description

    Insert the mini SIM card (2FF) with the gold contact facing down. SIM Card Slot Push the mini SIM card (2FF) inwards to eject it * Power off the BEC 4700AZ before inserting or removing the SIM card(s) Wireless connection established Green 2.4GHz...
  • Page 16 Product Overview Device Description (Hardware Overview (BEC 4700A)) PORT & LED MEANING Green RSSI greater than -69 dBm. Excellent signal condition Green Flashing Quickly RSSI from -81 to -69 dBm. Good signal condition LTE LED Orange Flashing Quickly RSSI from -99 to -81 dBm. Fair signal condition...

  • Page 17: Hardware Overiew (Bec 4700A)

    Product Overview Device Description (Hardware Overview (BEC 4700A)) Hardware Overiew (BEC 4700A) PORT & LED MEANING WIFI Antenna Screw the supplied 2.4GHz antennas onto the antenna connectors on both sides. Connectors (2.4GHz) After the device is powered on, press it 6 seconds or above: to restore to factory default RESET settings (this is used when you cannot login to the router, e.g.
  • Page 18 Product Overview Device Description (Hardware Overview (BEC 4700A)) PORT & LED MEANING Green System is up and ready Power LED Boot failure Green IP connected; WAN connection is ready Internet LED IP request failed Either in bridged mode or WAN connection is not available Use an outdoor Ethernet cable to connect to any Ethernet equipment.

  • Page 19: Mounting Kit Installation

    Hose Clamp x 2 ❖ M6 Washer x 2 ❖ Spring Washer x 2 ❖ Stainless Hose Clamp x 2 M6 x 60 Screw Bolt x 2 M6 Washer x 2 Spring Washer M6 x 2 BEC 4700A / 4700AZ User Manual...
  • Page 20 Mounting Kit Installation 1. Attach the Articulation Pole to the Enclosure Attach the articulation pole to the back of the BEC 4700A/AZ enclosure using the supplied M6 screws, M6 spring washers and M6x16 screws which are included in the mounting kit.
  • Page 21 Product Overview Mounting Kit Installation Note: The flexible mounting kit can be adjusted in multiple angles to align with the base station for higher efficiency. 45∘ 45∘ 45∘ 45∘ BEC 4700A / 4700AZ User Manual...
  • Page 22 Attach the T-formed Bracket and the W-bar to the pole then use M6x60 bolts, M6 spring washers and M6 washers to fix the mounting kit onto the pole. 2.3 Mounting on a Pole between 1” to 3” (25.4 ~ 76.2mm) BEC 4700A / 4700AZ User Manual...
  • Page 23 3. Install the Articulation Pole with the T-formed Bracket Attach the articulation pole (BEC 4700A/AZ enclosure) to the T-formed bracket using the supplied M8 nut, M8 spring washer, M8 washer and M8x40 screw bolt. M8 Washer...
  • Page 24 Attach the grounding wire to the BEC 4700A/AZ and tighten the screw 5. Position Adjustment Adjust the 4700A/AZ until it reaches the desire elevation and depression angle, then tight the M8 nut (see Install the Articulation Pole with the T-formed Bracket for more information)

  • Page 25: Router Installation Instructions

    Product Overview Router Installation Instructions Router Installation Instructions 1. Power on your BEC 4700A/AZ Step 1: Assemble M25 cable gland Step 2: Unscrew the WAN/PoE IN port and insert the supplied outdoor Ethernet cable (RJ-45) through material A-D, and then connect the RJ-45 Ethernet cable into the WAN/PoE IN port.
  • Page 26 Gigabit PoE injector Data+Power port. Connect another Ethernet cable (RJ-45) directly to the Data port and the other end of cable to a switch or broadband router. Powering via a PoE Switch: Connect the Ethernet cable (RJ-45) from the 4700A/AZ directly to a PoE port on the switch.
  • Page 27 Step 2 (4700AZ Only): Slide the SIM card with the mental contacts (gold plate) facing down to the SIM slot then push it all the way in until you hear the clicking sound. It is recommended to use an industrial-grade SIM card. BEC 4700A / 4700AZ User Manual...
  • Page 28 Product Overview Router Installation Instructions Step 3 (4700AZ Only): Screw the cap back tightly. Please power off the device before inserting or removing the SIM card. BEC 4700A / 4700AZ User Manual...

  • Page 29: System Recovery Procedures

    System Recovery Procedure System Recovery Procedures The purpose is to allow users to restore the BEC 4700A/AZ to its initial stage when the device is outage, upgraded to a wrong / broken firmware, cannot access to the GUI with wrong username and/or password, etc.

  • Page 30: Chapter 3: Basic Installation

    If not, please refer to your Windows-related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the BEC 4700A/AZ. To configure other types of workstations, please consult the manufacturer’s documentation. Attention...

  • Page 31: Network Configuration - Ipv4

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 4700A / 4700AZ User Manual...
  • Page 32 Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 4700A / 4700AZ User Manual...

  • Page 33: Configuring Pc In Windows 7/8 (Ipv4)

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 4700A / 4700AZ User Manual...
  • Page 34 Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 4700A / 4700AZ User Manual...

  • Page 35: Configuring Pc In Windows Vista (Ipv4)

    Center at the top bar. When Network and Sharing Center window pops up, select and click on Manage network connections on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 4700A / 4700AZ User Manual...
  • Page 36 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 4700A / 4700AZ User Manual...

  • Page 37: Network Configuration - Ipv6

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 4700A / 4700AZ User Manual...
  • Page 38 Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 4700A / 4700AZ User Manual...

  • Page 39: Configuring Pc In Windows 7/8 (Ipv6)

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 4700A / 4700AZ User Manual...
  • Page 40 Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 4700A / 4700AZ User Manual...

  • Page 41: Configuring Pc In Windows Vista (Ipv6)

    Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. BEC 4700A / 4700AZ User Manual...
  • Page 42 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. BEC 4700A / 4700AZ User Manual...

  • Page 43: Default Settings

    Device LAN IP Settings IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 DHCP Server: DHCP server is enabled. Start IP Address: 192.168.1.100 IP pool counts: 100 BEC 4700A / 4700AZ User Manual...

  • Page 44: Information From Your Isp

    DHCP Client (it can be automatically assigned by your ISP when Dynamic IP Address you connect or be set manually). IP address, Subnet mask, Gateway address, and Domain Name Static IP Address System (DNS) IP address (it is fixed IP address). BEC 4700A / 4700AZ User Manual...

  • Page 45: Chapter 4: Device Configuration

    The default username & password is “admin” & “admin” respectively for the Administrator. NOTE: This username / password may vary by different Internet Service Providers. Congratulations! You have successfully logged on to your BEC 4700A/AZ BEC 4700A / 4700AZ User Manual...
  • Page 46 Device Configuration Login to Your Device Once you have logged on to your BEC 4700A/AZ via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you...
  • Page 47 Device Configuration Login to Your Device Firmware & Configuration System Restart Auto Reboot Diagnostic Tool Please see the relevant sections of this manual for detailed instructions on how to configure your BEC 4700A/AZ. BEC 4700A / 4700AZ User Manual...

  • Page 48: Status

    Model Name: Name of the router for identification purpose. Firmware Version: Software version currently loaded in the router. MAC Address: A unique number that identifies the router. Data Time: Setup correct time on the BEC 4700A/AZ with your PC. Check on Time Zone section for more configuration information.
  • Page 49 Mode: Display selected Wireless mode. SSID: Display the name of the Wireless AP(s) to use. Channel: Display radio frequency to be used for this wireless link. Security: Display security method to be used for this wireless link. BEC 4700A / 4700AZ User Manual...

  • Page 50: System Status

    In system log, you can check the operations status and any glitches to the router. Refresh: Press this button to refresh the statistics. Backup: Press to save the System log, log.cfg, to your PC. BEC 4700A / 4700AZ User Manual...

  • Page 51: 4G/Lte Status

    Auto Refresh: Select Disable or Enable to reload the mobile status information. Refresh: Click to refresh the statistics. Usage Allowance >> click “Usage To enable this feature, please go to Configuration >> Interface Setup >> Internet Allowance” >> enable “Save the statistics to ROM” BEC 4700A / 4700AZ User Manual...
  • Page 52 Amount Used: Display the amount of mobile data used and remaining in current billing cycle. Billing Cycle: Display the start date and number of days remaining in current billing cycle. Clean: Reset current saved mobile usage. Save: Click to save current mobile status to ROM. BEC 4700A / 4700AZ User Manual...

  • Page 53: Wireless Status

    Host Name: Display the hostname of the Wi-Fi client. IP Address: The LAN IP address assigned to the wireless device. Expire Time: Display remaining time before connection expires or timeout. Refresh: Click to refresh the statistics. BEC 4700A / 4700AZ User Manual...

  • Page 54: Hotspot Status

    Upload / Download (used / available bandwidth in %): Display current used bandwidths, in upload and download, out of the maximum allow usage in %. Total Data Usage: Display total data usage of the Wi-Fi user. Refresh: Click to refresh the statistics. BEC 4700A / 4700AZ User Manual...

  • Page 55: Statistics

    Receive Speed: Display the data rate receives from the mobile Internet. Refresh: Click to manually refresh the data. Auto Refresh: Select a time interval to refresh the data automatically or none to disable the feature. BEC 4700A / 4700AZ User Manual...
  • Page 56 Receive Speed: Display the data rate receives from the Broadband Internet Service Provider. Refresh: Click to manually refresh the data. Auto Refresh: Select a time interval to refresh the data automatically or none to disable the feature. BEC 4700A / 4700AZ User Manual...
  • Page 57 Receive Speed: Display the data rate receives from the Broadband Internet Service Provider. Refresh: Click to manually refresh the data. Auto Refresh: Select a time interval to refresh the data automatically or none to disable the feature. BEC 4700A / 4700AZ User Manual...
  • Page 58 Receive Speed: Display the data rate receives from the Wireless AP. Refresh: Click to manually refresh the data. Auto Refresh: Select a time interval to refresh the data automatically or none to disable the feature. BEC 4700A / 4700AZ User Manual...

  • Page 59: Dhcp Table

    Statistics: Display upstream/downstream traffic per session in KB. The value clears when session disconnects. Remote Gateway: Display remote gateway IP address. Remote Network: Display remote local IP address and Netmask. Local Network: Display local IP address and Netmask. Refresh: Click to refresh the page. BEC 4700A / 4700AZ User Manual...

  • Page 60: Pptp Status

    Server IP Address: Display the WAN IP address of remote PPTP Server. Remote Network: Display the remote network address and subnet mask in LAN to LAN PPTP connection. Refresh: Click to refresh the page. BEC 4700A / 4700AZ User Manual...

  • Page 61: L2Tp Status

    Active: Display Yes or No to indicate the profile is enabled or disabled. Connection State: Display Yes/No to indicate the VPN connection status. Remote Gateway IP: Display the remote gateway IP address. Remote Network: Display the remote local network IP address / Netmask. BEC 4700A / 4700AZ User Manual...

  • Page 62: Openvpn Status

    Remote Server: Display the remote server public IP address and used port/protocol for this connection. Status: Display the status of the profile/rule Detailed Info: Display detailed IP assignment and routing information of this VPN connection. Refresh: Click to refresh the page. BEC 4700A / 4700AZ User Manual...

  • Page 63: Arp Table

    IP Address: It is IP Address of internal host that join this network. MAC Address: The MAC address of internal host. VRRP Status Current Status: Display current VRRP status, Master or Backup. Current Master: Display the IP address of the Master. BEC 4700A / 4700AZ User Manual...

  • Page 64: Quick Start

    Step 2 – Time Zone Choose your time zone. Click NEXT to continue. Step 3 – Wireless Set up your wireless connection if you want to connect to the Internet wirelessly on your PCs. Click NEXT to continue. BEC 4700A / 4700AZ User Manual...
  • Page 65 Set up your WAN Internet connection. 4.1 Select an appropriate WAN connection protocol then click NEXT to continue. 4.2 If selected 4G/LTE (for example) Input all relevant 4G/LTE parameters from your ISP. Click Next to save changes. BEC 4700A / 4700AZ User Manual...
  • Page 66 The Setup Wizard has completed. Click on BACK to make changes or correct mistakes. Click NEXT to save the current settings and complete the Quick Start setups. Go back to the Status > Device Info to view the status. BEC 4700A / 4700AZ User Manual...

  • Page 67: Configuration

    These functions are described in the following sections. Interface Setup Here are the features under Interface Setup: Internet, LAN, Wireless 2.4G, Wireless MAC Filter, Wireless 5G, Wireless 5G MAC Filter, Wireless 5G Repeater, and Loopback. Internet ❖ 4G/LTE ❖ 4G/LTE (Cont.) BEC 4700A / 4700AZ User Manual...
  • Page 68 Usage Allowance: Click Enable to activate the feature. Click the link to setup the usage settings. Period: Pick a period, Month or Day. Mode: Include Volume-based and Time-based control.  Volume-based include “only Download”, "only Upload”, and “Download and Upload” to limit BEC 4700A / 4700AZ User Manual...
  • Page 69 IP address, features such as routing capabilities, NAT, firewall, etc., will be disabled by default. However, the client router behind the BEC 4700A/AZ can get a WAN IP address instead. When disabled, BEC 4700A/AZ is in router mode that it handles a WAN IP address and all routing- related features become available.
  • Page 70 Keep Alive: Select Yes to ensure the 4G/LTE internet connection is always available. Keep Alive IP: Enter the IP address that the 4700A/AZ can ping the IP to find whether the connection is on or not, if not, router will recover the connection.
  • Page 71 VLAN ID: It is a parameter to specify the VLAN which the frame belongs. Enter the VLAN ID identification, tagged: 0-4095. Dynamic IP Address (If selected as WAN Connection Type; otherwise, skip this part) BEC 4700A / 4700AZ User Manual...
  • Page 72 1492 bytes. IPv4 Options NAT: Enable to allow BEC 4700A/AZ to assign private network IPs to all devices in the network for get Internet access. Client ID: It is known as DHCP Option 61. Enter the client identifier from your ISP.
  • Page 73 Gateway: Enter the specific gateway IP address you get from ISP. Primary / Secondary DNS Server: Enter the IP addresses of the DNS servers. The DNS servers are passed to the DHCP clients along with the IP address and the subnet mask. BEC 4700A / 4700AZ User Manual...
  • Page 74 Device Configuration Interface Setup – Internet (WAN on Ethernet) NAT: Enable to allow BEC 4700 to assign private network IPs to all devices in the network for get Internet access. Dynamic Route  RIP Version: (Routing Information protocol) Select this option to specify the RIP version, including RIP-1, RIP-2.
  • Page 75 IN only means the router will only accept but will not send RIP packet. OUT only means the router will only send but will not accept RIP packet. IGMP Proxy: IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish BEC 4700A / 4700AZ User Manual...
  • Page 76 DNS. MLD Proxy: MLD (Multicast Listener Discovery Protocol) is to IPv6 just as IGMP to IPv4. It is a Multicast Management protocol for IPv6 multicast packets. Click Save to apply settings. BEC 4700A / 4700AZ User Manual...

  • Page 77: Lan

    IN only means the router will only accept but will not send RIP packet. OUT only means the router will only send but will not accept RIP packet. DHCPv4 Server BEC 4700A / 4700AZ User Manual...
  • Page 78  If set to Disabled, the DHCP server will be disabled.  If set to Relay, the BEC 4700A/AZ acts as a surrogate DHCP server and relays DHCP requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.
  • Page 79 When using stateless configuration, you needn’t configure anything on the client. Stateful configuration, for example using DHCPv6 (which resembles its counterpart DHCP in IPv4.) In the stateful auto configuration model, hosts obtain interface addresses and/or configuration BEC 4700A / 4700AZ User Manual...
  • Page 80 Router Advertisement messages periodically which would multicast the IPv6 Prefix information (similar to v4 network number 192.168.1.0) to all LAN devices if the field is enabled. We suggest enabling this field. Click Save to apply settings. BEC 4700A / 4700AZ User Manual...

  • Page 81: Wireless 2.4Ghz

    LAN cards communicating through access points which bridge network traffic to the wired LAN. NOTE: WLAN (or BEC)1 / 2 / 3 / 4 Interface refers to as SSID1 / 2 / 3 / 4 Wi-Fi networks. Access Point Settings Site Survey: Click to view all other available Wireless-AP devices near the BEC 4700A/AZ.
  • Page 82 The shorter the Guard Interval, the better the performance will be. We recommend users to select Auto. MCS (Modulation and Coding Scheme): There are options 0~7 and AUTO to select from. AUTO is most recommended. BEC 4700A / 4700AZ User Manual...
  • Page 83 WEP and WPA. There are five alternatives to select from: Open (no security protected), WEP 64-bit, WEP 128-bit, WPA-PSK, WPA2-PSK and Mixed WPA/WPA2-PSK. If you require high security for transmissions, please select WPA-PSK, WPA2-PSK or WPA/WPA2-PSK. BEC 4700A / 4700AZ User Manual...
  • Page 84 Pre-Shared key: The key for network authentication. The input format should be 8-63 ASCII characters or 64 hexadecimal characters Key Renewal Interval: The time interval for changing the security key automatically between wireless client and AP. BEC 4700A / 4700AZ User Manual...
  • Page 85 AP. WDS Mode: select Activated to enable WDS feature and Deactivated to disable this feature. MAC Address: Enter the AP MAC addresses (in XX:XX:XX:XX:XX:XX format) of the peer connected Click Save to apply settings. BEC 4700A / 4700AZ User Manual...

  • Page 86: Wireless Mac Filter

     Select Allow to permit access to the router, MAC addresses not listed will be denied access to the router. MAC Address: Enter the MAC addresses (in XX:XX:XX:XX:XX:XX format) of the wireless station that are allowed or denied access to the specified in these address fields. Click Save to apply settings. BEC 4700A / 4700AZ User Manual...

  • Page 87: Wireless 5Ghz

    Interface Setup – Wireless 5GHz Wireless 5GHz Access Point Settings Site Survey: Click to view all other available Wireless-AP devices near the BEC 4700A/AZ.  CH (Channel): Channel ID used.  SSID: The name of the wireless AP.  BSSID: The MAC address of the wireless AP.
  • Page 88 Wi-Fi network for a residential or an office setting. WPS supports 2 types of configuration methods which are commonly known among consumers: PIN Method (Personal Information Number) & PBC Method (Push Button Configuration). BEC 4700A/AZ offers PIN Method only.
  • Page 89 WDS (Wireless distributed system) is a wireless access point mode that enables wireless link and communication with other access point. It is easy to be installed, just define the peer’s MAC of the connected AP. BEC 4700A / 4700AZ User Manual...
  • Page 90 Interface Setup – Wireless 5GHz WDS Mode: select Activated to enable WDS feature and Deactivated to disable this feature. MAC Address: Enter the AP MAC addresses (in XX:XX:XX:XX:XX:XX format) of the peer connected Click Save to apply settings. BEC 4700A / 4700AZ User Manual...
  • Page 91 Interface Setup – Wireless (Example on WPS using PIN) Example: WPS using PIN Method (Personal Information Number) PIN Method – Configure BEC 4700A/AZ as a Registrar 1. Jot down the client’s Pin (e.g. 04640776) from the WPS utility (e.g. Ralink Utility) 2.
  • Page 92 Interface Setup – Wireless (Example on WPS using PIN) 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the registrar, the BEC 4700A/AZ router. BEC 4700A / 4700AZ User Manual...
  • Page 93 PIN Method – Configure BEC 4700A/AZ as an Enrollee 1. Jot down the AP PIN Code (e.g. 03454435) from the BEC 6300VNL. Press Start WPS. 2. Launch the wireless client’s WPS utility (e.g. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code (e.g.
  • Page 94 Device Configuration Interface Setup – Wireless (Example on WPS using PIN) 3. The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar (client). BEC 4700A / 4700AZ User Manual...

  • Page 95: Wireless 5G Mac Filter

     Select Allow to permit access to the router, MAC addresses not listed will be denied access to the router. MAC Address: Enter the MAC addresses (in XX:XX:XX:XX:XX:XX format) of the wireless station that are allowed or denied access to the specified in these address fields. Click Save to apply settings. BEC 4700A / 4700AZ User Manual...

  • Page 96: Wireless 5G Repeater

    Device Configuration Interface Setup – Wireless 5G Repeater Wireless 5G Repeater Use the BEC 4700A/AZ as a repeater to extend the wi-fi signal of the primary AP. Manually Fill-in SSID: Enter the SSID of the primary AP. Security Type: Enter the Wi-Fi security type of the primary AP.

  • Page 97: Loopback

    Telnet management IP and involved in BGP as BGP Update-Source and OSPF as Router ID. IP Address: Enter a dedicated IP address for the loopback interface. IP Subnet Mask: Enter the subnet mask for the loopback interface. Click Save to apply settings BEC 4700A / 4700AZ User Manual...

  • Page 98: Dual Wan

    Dual WAN, is a feature to have two independent Internet connection connected concurrently, offers a reliable Internet connectivity and maximize bandwidth utilization for critical applications delivery. General Setting Mode: Select a mode then click Save to proceed. BEC 4700A / 4700AZ User Manual...
  • Page 99 (WAN2) after primary link fails to response in total of 90 seconds, 30 seconds for 3 consecutive failures. Note: Failover and Failback follow the same Connectivity Decision & Probe Cycle rule to failover from WAN1 to WAN2 or fallback from WAN2 to WAN1. BEC 4700A / 4700AZ User Manual...
  • Page 100 The valid range is from -111 ~ -5. 0 means don’t care/no need to check this value. NOTE: Both the RSRP and RSSI cannot be 0 at the same time. Click Save to apply settings. BEC 4700A / 4700AZ User Manual...
  • Page 101  Gateway: Internal system will wait for responses to the pings from the gateway of the WAN.  Host: Internal system will wait for responses to the pings from a fixed IP address. Click Save to apply settings BEC 4700A / 4700AZ User Manual...

  • Page 102: Outbound Load Balance

    Balance by weight: Use an IP hash to balance traffic based on a ratio. It is to guarantee requests from the same IP address get forward to the same WAN interface. Click Save to apply settings BEC 4700A / 4700AZ User Manual...

  • Page 103: Protocol Binding

    Click Save to apply settings Example: All traffics from IP 192.168.1.100/255.255.255.0 with port 8080 will go through WAN1 interface. The only time it would go through WAN2 interface is when WAN1 has no Internet connection. BEC 4700A / 4700AZ User Manual...
  • Page 104 Device Configuration Dual WAN – Protocol Binding BEC 4700A / 4700AZ User Manual...

  • Page 105: Hotspot

    URL. OR leave it blank to stay in current page. NOTE: This new URL will be added to the Walled Garden automatically. BEC 4700A / 4700AZ User Manual...
  • Page 106 Secondary RADIUS Server: The backup IP address of the server, if any.  Shared Secret Key: Enter the shared Secret given by the server  Built-in User Account (local database handled by the BEC 4700A/AZ)  Go to the Built-in User Account to setup account usernames and passwords for the hotspot.
