11.6 View Function (VIEW key)

11.6.1 Position Display

Trigger time
Time from trigger point
(MEM, RMS, memory waveform in REC&ME
Time from starting record
(Recorder, recorder waveform in REC&MEM)
────────────────────────────────────────────────────
11.6 View Function (VIEW key)
Indicates the position of the currently displayed waveform within the entire
recording length.
The trigger time, trigger position and A･B cursor position are displayed
when using the vertical or trace cursors. There is no particular view for the
FFT function.
When the recording length is 200 divisions:
Time axis magnification ratio: × 1
Time axis magnification ratio: × 2
Time axis magnification ratio: × 1/2
Procedure
1. Press the
2. Use the function keys to move the (
3. Select the
Trigger position A cursor
T
Screen: Waveform display
key on the Waveform display screen.
VIEW
The position is displayed at lower of the screen.
desired point with function key.
Slide the bar graph cursor to select from 0, 25, 50, 75,
and 100% of full recording length, trigger point, and A
and B cursors.
Function
display Meaning
: Shifts the destination to the left.
: Shifts the destination to the right.
: Executes the dislocation.
: Toggles block display.
function key. The high-speed shift is
(exec)
carried out and the display position changes.
B cursor
A
Displayed part (25 divisions)
Displayed part
Displayed part
) mark to the
B
