While a sweep is in progress, the wavelength limits and the present
wavelength are shown. The slider will move, showing the progress of the
sweep.

Status Bar

The first part of the status bar displays messages. In addition, it shows the
current application mode (Normal or High Resolution).
The second part of the status bar displays the inscription Local, Remote, or
Lockout, which indicates if the IQ-2600B is controlled locally or remotely.
For more information on how to control the different IQ modules remotely,
refer to the GPIB and Application Development Guide. Table 1-4 explains
the meaning of these inscriptions.
Indication
Local
Remote
Lockout
Finally, the status bar displays the time.
Tunable Laser Source
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Meaning
The unit is controlled locally.
The unit is controlled remotely, but local
commands can still be used.
The unit is controlled remotely.
Table 1-4. Module Control Status
